.: Gebze Institute of Technology Electronics Engineering Department

Mr.Deniz ELMASLI Master's Thesis

.: E-Polarized Wave Scattering from from Infinitely Thin and Finitely Width Strip Systems

Fourier-Chebyshev Expansions of Equation Terms

• By using Chebyshev Polynomials these identities can be defined;

• Above formulas Fourier-Chebyshev coefficients

are needed for finding JD(p).

• Coefficients of;

are used to find:

coefficients.

• By using Gauss of LU matrix solver, #13; Xn values can be found.

• How fourier-chebyshev expansion is being calculated :
