.: Gebze Institute of Technology Electronics Engineering Department

Mr.Deniz ELMASLI Master's Thesis

.: E-Polarized Wave Scattering from from Infinitely Thin and Finitely Width Strip Systems

Local Singular Expantion

Local Singular Expantion for;

• As it is known well known that

is parametrized Green function for

and Green function for 2 dimensional Space has a singularity for its Neumann Function inner ln quality.

For:

case singularity expansion can be applied.

• As we know that zero order first kind Hankel Function is:

• J0(z) and Y0(z) are correspondently zeroth order Bessel and Neumann functions which can be extracted as below power series.
