Engine: 4-stroke, 4-cycle, overhead valve, air cooled
Engine Capcity: 49cc (2.99 cu. in. ) , 40mm bore x 39 mm stroke
position - 2nd from top ; Slide Valve #2.0
Electrical: Flywheel Magneto, 6v 38 Watt with rectofier in system
Spark Plugs - Champion Z8 , A.C. S102f Autolite PX2 , Bosch U200L
NGK C7H5
Bulbs: Headlamp - 6v 25 Watt
Tail Light - #1154 - 6V
Speedo Indicator Bulb #51- 6V
Turn Signal Bulb #81 - 6V
Horse Power Rating : 1.2 - 1.9 horse power adjusted to meet state regulations.
Transmission: 1 speed automaticwith chain drive , quick release pedal drive.
Frame: Pressed steel, monocoque, covered by a lifetime warrenty.
Gas Tank Capicity 1.4 gallons
Oil Capacity - 24 ounces
Brakes: Internal expanding, twin shoe front and rear, operated by hand levers.
Suspension: Hevy duty hydraulic front forks - spring loaded rear shocks
Tires: 2.25 x 17 nylon cord 4-ply rating with 300 lb. load rating front and rear at 30 mph (Indian brand made by Chen Shin). Maintain both front and rear tire pressure at 40-45 P.S.I.
Wheels: 12 guage spokes with aluminum alloy hubs
Weight : 119 lbs
Dimensions: 69 inches, wheelbase 43 1/4 inches, seat height 31 inches
Rocker Arm Adjustment: .002 [cold]
Contact Breaker Points: .012 - .016
Spark Plug Gap: .024 - .028
Torque for head bolts and valve cover:; 75 in. lbs
Torque for clutch nut: 160 in. lbs.
