Ref.No |
Partnumber |
Description |
Reqd. |
| 1 | 16010-371-004 | PACKING SET | 4 |
| 2 | 16011-371-004 | VALVE SET, FLOAT | 4 |
| 3 | 16012-431-004 | NEEDLE SET, JET | 4 |
| 4 | 16013-567-004 | FLOAT SET | 4 |
| 5 | 16016-431-004 | SCREW SET A | 4 |
| 6 | 16022-431-004 | PISTON SET. VACUUM | 4 |
| 7 | 16165-371-770 | HOLDER, NEEDLE JET | 4 |
| 8 | 16166-371-770 | NOZZLE, MAIN | 4 |
| 9 | 93500-04008-OA | SCREW, PAN, 4x8 | 4 |
| 10 | 93500-04014-OA | SCREW, PAN, 4x14 | 4 |
| 11 | 93500-05016-OA | SCREW, PAN, 5x16 | 8 |
| 12 | 94111-04000 | WASHER, SPRING, 4MM | 8 |
| 13 | 94111-05000 | WASHER, SPRING, 5MM | 8 |
| 14 | 94303-04065 | PIN C, DOWEL, 4x6.5 | 8 |
| 15 | 99103-611-0350 | JET, SLOW, #35 | 4 |
| 16 | 99164-601-0600 | JET, SECONDARY AIR, #60 | 4 |
| 17 | 99164-601-1200 | JET, PRIMARY AIR, #120 | 8 |
| 18 | 99201-601-0600 | JET SET, PRIMARY MAIN (#60) | 4 |
| 19 | 99202-601-1200 | JET SET, SECONDARY MAIN, #120 | 4 |
