Ref.No
|
Partnumber
|
Description
|
Reqd.
|
| 1 |
28101-371-003 |
CHAIN, STARTING (DAIDO) |
1 |
| 2 |
28111-371-000 |
SPROCKET, STARTING |
1 |
| 3 |
2812O 371-000 |
CLUTCH, STARTING |
1 |
| 4 |
28125-516-030 |
SPRING, STARTING CLUTCH ROLLER |
3 |
| 5 |
28126-516-020 |
CAP, STARTING CLUTCH ROLLER SPRING |
3 |
| 6 |
31100-371-013 |
A.C. GENERATOR ASSY. (KOKUSAN) |
1 |
| 7 |
31110-371-003 |
FLYWHEEL COMP. ( KOKUSAN) |
1 |
| 8 |
31120-371-013 |
STATOR COMP. (KOKUSAN) |
1 |
| 9 |
90015-371-003 |
SCREW, FLAT, 8x22 |
3 |
| 10 |
90023 371 000 |
BOLT, SET, 12x40 |
1 |
| 11 |
90401-371-000 |
WASHER, 12.2x33x3.2 |
1 |
| 12 |
90454-371-000 |
WASHER, THRUST, 25x21 |
1 |
| 13 |
90605-371-000 |
CIR CLIP, INTERNAL, 33MM |
2 |
| 14 |
91101-371-006 |
BEARING, NEEDLE, 28x33x26 |
1 |
| 15 |
91101-516-000 |
ROLLER, 15x13 |
3 |
| 16 |
91354-371-000 |
O-RING, 23MM |
1 |
| 17 |
93500-06040 |
SCREW, PAN, 6x40 |
3 |
| 18 |
94511-26000 |
CIR CLIP, EXTERNAL, 26 |
1 |
