JBL NSP1 "Voiced Matched" - HT Speaker Package (MSRP $549) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Read MY JBL's NSP1 Speaker Review |
|
|
|
|
|
|
|
|
|
|
|
Purchased NSP1 from shop.theglobe.com for $223.87 Total Ordered: 4/24/00 Received: 4/27/00 (No CA Tax, includes S/H / used 15% off coupon and previously earned $42 Globe$$ - shop.theglobe.com no longer sells Electronics) |
|
|
|
|
|
|
|
The 2-way 4" bookshelf loudspeakers and the 2-way dual 5" center-channel loudspeaker with high-impact molded enclosure reproduce sound with unmatched clarity and power.
� The PolyPlas� (polymer-coated cellulose fiber) cone woofer features traditional JBL engineering; the same technologies used in JBL's Professional equipment that can be found in stadiums, music halls and movie theaters around the world. � Shielded components allow placement near video monitors. High-temperature, oversized Kapton� voice coil and HeatScape� motor structure allow these speakers to effortlessly play all types of movies and music. The FreeFlow� flared port increases bass response without adding unwanted port noise. JBL's custom-designed drivers allow the use of simple, Straight-line Signal Path� (SSP) crossover networks with high-quality electrical components that minimize processing that could degrade the signal. |
|
|
|
|
|
|
Read JBL's 1999 Speaker Lineup by dba newsline - Aug. 19, 1999 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
JBL N Center (shielded) |
|
|
|
|
|
Features:
N Center Channel speaker
Max Recommended Amplifier Power: 150W
Design: Dual Ported (bass reflex)
Nominal Impedance: 8 Ohms
Sensitivity (2.83V/1m): 90dB
Frequency Response (�3dB): 80Hz � 20kHz
Crossover Frequency: 3500Hz
High-Frequency Transducer: 3/4" Titanium-laminate dome, shielded
Low-Frequency Transducer: 5" x 2 PolyPlas�, shielded
Finish: Dark gray Molded plastic cabinet
Grille Color: Gray cloth
Five-way binding-post terminals
Dimensions (H x W x D): 6-1/2" x 20-1/2" x 8-1/2"
Weight Per Speaker: 10lbs |
|
|
|
|
|
|
|
|
|
|
JBL N24 (shielded) |
|
|
|
|
|
|
|
|
|
|
|
Features:
N24s - Two-way bookshelf/satellite speaker
Max Recommended Amplifier Power: 100W
Design: Ported (bass reflex)
Nominal Impedance: 8 Ohms
Sensitivity (2.83V/1m): 86dB
Frequency Response (�3dB): 75Hz � 20kHz
Crossover Frequency: 3000Hz / First-order (6 dB/octave)
High-Frequency Transducer: 3/4" Titanium-laminate dome, shielded
Low-Frequency Transducer: 4" PolyPlas�, shielded
Finish: Dark gray Molded plastic cabinet
Grille Color: Gray cloth (N24)
Threaded rear socket for OmniMount-type bracket Threaded bottom socket for JBL speaker stand Five-way binding-post terminals
Dimensions (H x W x D): 9-1/2" x 6-1/4" x 4-3/4"
Weight Per Speaker: 4.5lbs |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Read JBL's NSP1 Speaker Review by Brent Butterworth - Aug. 3, 2000 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Read Why you should audition JBL speakers! |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
NSP1 HT Speaker Package includes: four - OmniMount-type brackets & tools |
|
|
|
|
|
|
Click to see a closeup of the NSP1 HT Package |
|
|
|
|
|
|
|
|
|
|
Compare the JBL NSP1's Frequency Response with other equivalent and more expensive speakers |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
PI - May 1, 2000 |
|
|
|
|
|
|
|
|
|
(To previous page) |
|
|
(Sub-woofer Specifications) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
