| Monitor Visual Sensation
VS-7p |
VS-7p
17"
(16.0" vis) Professional Business Color Monitor With
unprecendented image quality in a 17-inch design, the new
VS-7p is unquestionably the monitor of choice for home users
and business professionals. With a .23(H)mm dot pitch for
crisp images and high refresh rates that eliminate eye strain,
the VS-7p is the ideal solution for the home or office. The
VS-7p is fully protected under KDS' exclusive KARES program,
insuring peace of mind in addition to excellent
performance. |
| |
|
Cathode Ray Tube |
|
|
Size :
|
17-inch diagonal measure (16.0"
viewable) |
|
Screen :
|
Anti-reflective
coated |
|
Dot Pitch :
|
0.24 mm (horizontal) |
|
Phosphor :
|
P22 |
| Video |
|
|
Input :
|
15 pin D-sub; RGB analog, 0.70 V
p-p |
|
Dot Clock :
|
110 MHz (max) |
|
Transient Response
: |
< 10 ns between 10-90
percent |
|
Synchronization |
|
|
Polarity :
|
TTL pos/neg |
|
Frequency :
|
30-70 kHz (horizontal)50-160 Hz
(vertical) |
|
Retrace Period
: |
3.0 µs
(max horizontal)300
µs (max
vertical) |
|
Raster Specifications |
|
|
Display Size :
|
310? mm 232? mm |
|
Maximum Resolution
: |
1280 x 1024 @ 60 Hz |
|
Optimal Resolution
: |
1024 x 768 @ 85 Hz |
|
Electrical |
|
|
Voltage :
|
100-240 VAC, 50/60 Hz |
|
Power :
|
< 80 W |
|
Inrush Current
: |
50 A (max) |
|
Physical |
|
|
Operating Environment
: |
0-40 °C
(32-104 °F) 5-60 % humidity,
NC |
|
Dimensions :
|
406 x 430 x 410 mm (W x H x D)16.0
x 17.0 x 16.1 inches |
|
Weight :
|
14.9 kg (32.8 lbs.)
Net |
|
Features |
|
|
General :
|
Multi Language On-screen, digital
controlVESA DDC 1/2B Plug & PlayAuto degauss |
|
User Controls :
|
Contrast, brightness, H/V
size/position, color temperature (9300/6500) RGB drive, H/V
pincushion/H trapezoid/H/V convergence, raster rotation,
degauss |
|
Regulatory Approvals
: |
UL1950, CSA, TUV G/S, FCC Class B,
DHHS, MPR-II, ISO 9241-3, DEMKO, VCCI Class B, Nutek, EPA
Energy Star, VCCI,CE |
|
Warranty :
|
Three year
full |
| |
