Plasmon CD Libraries
CD-ROM Libraries
specifications
Plasmon CD Libraries |
Optical Resources offers
the industry's finest CD-ROM libraries from manufacturers such as NSM, Pioneer, Plasmon
and Sony. These disc storage units hold up to 500 CD-ROMs and as many as six
drives. Modern disc libraries feature an unprecedented amount of data storage and,
when combined with the high-speed performance of the latest CD-ROM drives, a library
offers the ideal networking tool for archival or multi-user environments. Performance
features include a sustained data transfer rate of up to 2.7 MB/second and a random
average seek time of less than 120 ms. The enhanced speed and performance of these
libraries is ideal for high-speed access to data across networks, for multiple users, or
for significantly increased data storage. The advanced CD-ROM drives integrated into
these units allows true realization of multimedia applications that employ full motion
video or imaging.
|
Manufacturer |
Model / Description |
| NSM | CDR100XA - up to 100 CDs, 1 drive |
| Mercury - up to 150 CDs or DVDs, up to 4 drives | |
| Satellite - up to 135 CDs or DVDs, up to 5 drives | |
| Galaxy - up to 620 CDs or DVDs, up to 14 drives | |
| Pioneer | DRM-1004X - up to 100 CDs, up to 4 drives |
| DRM-5004X - up to 500 CDs, up to 4 drives | |
| Plasmon | D-120 - up to 120 CDs, up to 4 drives |
| D240 - up to 240 CDs, up to 6 drives | |
| D480 - up to 480 CDs, up to 6 drives | |
| Sony CDL-1100-20 | 100 Disc CD-ROM Desktop Library for Single Users and Small Workgroups |
| CDL-1100-22N | 100 Disc CD-ROM Desktop Library for Windows NT� Networks |
| CDL-1100-23M | 100 Disc CD-ROM Desktop Library for Macintosh� Networks |
|
DR 100 XA, CDR
100 DVD and CDR 100 Recordable This is the NSM Jukebox solution for data archiving and replication in small and medium sized networks. The CDR 100 jukebox series build upon the same robotics and mechanics which have founded NSM's excellent reputation and its worldwide technology leadership in the area of highend jukeboxes for a range of applications. Additionally NSM's No Touch Technology ensures optimum data integrity since the media itself is protected against any kind of mechanical damage. The CDR 100 jukebox holds up to 100 CDs or 62.5 GB of data in two magazines of 50 CDs each. Choose between three versions of CDR 100:
NSM Jukebox delivers the CDR 100 as part of a complete solution. Software for all the major platforms, such as Windows NT, MacOS, UNIX etc is available from one source. CDR 100 XA / Recordable is the ideal solution for online access to large suites of Published CDs such as image catalogs or any kind of database. It is also suitable for archiving of data or efficient publishing of CDs. |
| Jukebox | Drives | System |
| Number of slots: 100 Data capacity: 65 GB (CD) | Number of drives: one | TDD: 7s |
| 470 GB (DVD-ROM) | CD-ROM | Data interface: SCSI-2 |
| 260 GB (DVD-RAM) | Type: TEAC CD-516 S | Robotics control interface: RS 232 |
| Magazines: 2, 50 media each | Data transfer rate: 2.4 MB/s | Weight 18kg, 40lb. |
| Media exchange 4,5s average | Access time: 115 ms | Height: 365mm, 14.4 in. |
| time: | CD-R | Width: 472mm, 18.3 in. |
| Media swap 2s average | Type: Plextor PX-R 412 | Depth: 215mm, 8.5 in. |
| time: | Data transfer rate: 600 KB/s write, | |
| Reliability: | 1.2 - 1.8 MB/s read | |
| Robotics MSBF: > 1,000,000 cycles | Access time: 190 ms | |
| Electronics MTBF: > 50,000 poh | DVD-RAM | |
| Type: Toshiba SD-W 1101 | ||
| Data transfer rate: 1 MB/s write, | ||
| 2.7 MB/s read | ||
| Access time: 120 ms |
|
The compact Mercury
Jukebox offers a gigantic storage potential of 100GB. The Mercury acclaimed "Product
of the Year" as well as the "Editors Choice" of Imaging Magazine excels in
performance in any network environment. The innovative lift mechanism along with the 4
drives will provide rapid access to all data. The Mercury Jukebox is fast, efficient and
can be extended by daisy chaining. Above all, it is multi-compatible and very reliable,
even under extreme working conditions. The optimized disc to drive ratio will ensure that
the Mercury can perform to its full potential on networks and substantially minimize the
occurrence of archive conflicts. The Mercury is a reliable investment for the future in
order to maintain your data in relation to state-of-the-art standards. ADVANTAGES OF THE MERCURY JUKEBOX: • Best Performance BASIC MODELS: Mercury 22 (2 read-only drives, 2 recorder drives) |
| Jukebox | Drives | System |
| Number of slots: 150 | Number of drives: four | TDD: 7s |
| Data capacity: 100 GB (CD) | CD-ROM Type: Plextor Px 32 | Data interface: SCSI-2 (differential |
| 705 GB (DVD-ROM) | Data transfer rate: 2.1 - 4.8 MB/s | ended opt.), |
| 390 GB (DVD-RAM) | Access time: 85 ms | Robotics control RS 232, SCSI-2 |
| Magazines: 3, 50 discs each | CD-R Type: Plextor Px-R 412 | interface: (differential ended |
| Media exchange < 4s average | Data transfer rate: 600 KB/s write, | opt.) |
| time: | 1.2 - 1.8 MB/s read | Weight: 29-32kg, 71lb. |
| Media swap time: 2s average | Access time: 190 ms | Height: 524mm, 20.6 in. |
| Reliability | DVD-RAM Type: Toshiba SD-W 1101 | Width: 272mm, 10.7 in. |
| Robotics MSBF: >2,500,00 cycles | Data transfer rate: 1 MB/s write | Depth: 601mm, 23.7 in. |
| Electronics MTBF: > 60,000 poh | 2.7 MB/s read | Media handling: no touch tray |
| Drive MLBF: > 250,000 load cycles | Access time: 120 ms | technology |
| Mail-slot: yes | ||
| LCD Operator NSM standard | ||
| panel: , 16 key 32 character | ||
| display |
|
Introducing Satellite, the third generation of the
NSM Jukebox family. Compact, fast and flexible, the NSM Satellite combines proven design
techniques with totally new features and capabilities. Its unique modular design provides
storage capacity for 60 to 135 CDs, and drive configurations from one to five. Satellite delivers quality, reliability and speed by using the robotics system proven in thousands of NSM Mercury juke-boxes worldwide. Innovative features of the Mercury series including no-touch tray technology, system controlled mail-slot, operator panel and user diagnostics have also been incorporated into the Satellite design as well as two totally new concepts in CD jukebox design, "Application Flexibility" and "Off-Line Data Management". The modular design of Satellite uses a standard PC form factor for each of the primary components of the jukebox: Packs, drives, and mail-slot. Each shares the same dimensions as a 5 1/4 inch half height internal device. Packs, drives and the mail-slot are interchangeable, allowing customized configurations of the jukebox. As a result, disc storage capacity, the number of drives and disk to drive ratios can be optimized to match the requirements of an individual application. For example applications which do not require a mail-slot can easily substitute an additional Pack for added data storage capacity. NSM Satellite Pack Management Satellite stores its data discs in convenient "Packs". Each Pack holds 15 CDs -10 GB of data stored in a compact form. NSM no-touch trays provide ideal handling and data security. Additional Packs allow the Satellite-system to provide secure "Off-Line" storage of data. And because Packs are easy to exchange, system storage capacity is expandable. The front Packs are "hot-swapable", allowing them to be ex- changed while the Jukebox system remains fully functional. The Satellite Jukebox features NSMs' exclusive "MemoryTrak" system. Each Pack contains an onboard memory device which includes a unique serial ID number. A rewritable area of the MemoryTrak allows the system to write and read important information about the data contents of each Pack. This allows the system to recognize the data contents of the Pack without re-scanning the discs. The NSM Satellite jukebox provides a system which combines fast accessibility and easy management over a virtually unlimited capacity of data. |
| Jukebox | Drives | Pack |
| Disc capacity: 60 to 135 media | Dimension: 1* | Disc Capacity: 15 CDs |
| Data capacity: 40 to 90 GB (CD) | Max number: 5 (up to 3 CD-R) | Memory Trak: 512byte |
| 248-635 GB (DVD-ROM) | CD-ROM | Identification unique serial ID-nr |
| 156-351 (DVD-RAM) | Type: Plextor Px 32 | System |
| Media exchange 2.5 sec. average | Data transfer rate: 2.1 - 4.8 MB/s | Data interface: dual bus SCSI-2 |
| time: | Access time: 85 ms | Robotics control RS 232, SCSI-2 opt. |
| Reliability | CD-R | interface: |
| Robotic MSBF: 2,500,000 cycles | Type: Plextor Px-R 412 | Weight: 24-26 kg, 53-57 lb. |
| Electronic MTBF: 60,000 (100% duty cycles) | Data transfer rate: 600 KB/s write, | (depending on config.) |
| Drive MLBF: 250,000 cycles | 1.2 - 1.8 MB/s read | Height: 409 mm, 16.2 in. |
| Mail-slot: 1* | Access time: 190 ms | Width: 240 mm, 9.5 in. |
| Operator panel: NSM standard, 16 keys, | DVD-RAM | Depth: 642 mm, 25.3 in. |
| 32 character display | Type: Toshiba SD-W 1101 | CD Handling: NSM no-touch tray |
| 1* standard half height form factor | Data transfer rate: 1 MB/s write | technology |
| 2.7 MB/s read | Dimension: 1* | |
| Access time: 120 ms | 1* standard half height form factor | |
| 1* standard half height form factor |
|
The latest jukebox from
NSM, the GALAXY, opens up a new dimension for storing large volumes of data.Using a
selection of either DVD RAM, CD or CDR drives the GALAXY has sufficient space for up to 3
TB of data. It is extremely robust, reliable and delivers excellent performance. Based on
NSM's vast experience in the development and design of jukeboxes, the GALAXY combines the
positive features of earlier models with a whole array of new function which will set new
standards in the industry. The GALAXY builds on this innovative jukebox concept. It can handle up to 620 media for long-term archiving or up to 14 drives for applications where maximum data through put has the highest priority. Like it's smaller family member, the Satellite, the number of media and drives can be adapted to the application's specific needs.This unique feature allows the correct match of storage capacity to performance needed.The GALAXY Jukebox is based on the concept of the Satellite in jukebox design. For the first time ever, it is possible, by using packs, to exchange a large number of media under system control while the jukebox is up and running.The application continuously monitors which media are removed from the jukebox and which new ones are added. This procedure ensures that all the data, On-line or Off-line, is controlled, allowing 100% data accessibility, unique in the Jukebox industry. The highlights
|
| Jukebox | Drives | System |
| Number of slots: 410 to 620 discs | Max number: 14 (CD-R up to 6) | Data interface: dual or triple bus SCSI-2 |
| Data capacity: 267 to 403 GB (CD) | CD-ROM | Robotics control SCSI-2/RS 232, |
| 1.9-2.9 TB (DVD-ROM) | Type: Plextor Px 32 | interface: switchable |
| 1.1-1.6 TB (DVD-RAM) | Data transfer rate: 2.1 - 4.8 MB/s | Weight: 85-100 kg(depending on |
| Media exchange 6 sec. average | Access time: 85 ms | config.) |
| time: | CD-R | Height: 1209 mm, 50.8 in. |
| Reliability | Type: Plextor Px-R 412 | Width: 365/625 mm, |
| Robotic MSBF: 2,500,000 cycles | Data transfer rate: 600 KB/s write, | 14.4/24.6 in. |
| Electronic MTBF: 60,000 (100% duty cycles) | 1.2 - 1.8 MB/s read | Depth: 665 mm, 26.2 in. |
| Drive MLBF: 250,000 cycles | Access time: 190 ms | CD Handling: NSM no-touch tray technology |
| Mail-slot: 1* | DVD-RAM | Pack |
| Operator panel: NSM standard, 16 keys, | Type: Toshiba SD-W 1101 | Disc capacity: 15 media Memory Trak: |
| 32 character display | Data transfer rate: 1 MB/s write 2.7 MB/s read | 512 Byte Identification: |
| Dimension: 1* | Access time: 120 ms | unique pack ID-nr |
| 1* standard half height form factor | 1* standard half height form factor | Dimension: 1* |
| 1* standard half height form factor |
|
The DRM-1004X10/40/R21 offers 65GB of total data
storage with less than 3 sec. disc change time. This high-performance, mid-range network
storage solution was designed primarily for quick, reliable performance in a high-demand
network environment. SRP starting at $6,495 |
| Product Name: | DRM-1004X10/40/R21 |
| Brief Description: | Pioneer's 100-disc CD-ROM jukeboxes, ideal for high performance, mid-range network storage applications. It combines data storage functions with both read and write capabilities all in one unit, and is designed for quick, reliable performance in a high-demand network environment. |
| Features: | -High speed
access to 100 CD-ROM discs. -Can be configured with up to four 12x readers, or with two 12x readers and one 4x writer. -Features two removable 50-disc magazines. -Convenient mail slot for easy loading and retrieving of discs. -User-friendly keypad and display. -Lockable front door for secure data. -High speed retrieval of text, graphics, audio and video databases. -Reliable storage for frequently accessed data on networks, electronic bulletin boards and similar environments. -Supports all major CD stands and formats |
| Specifications: | |
| Disc Capacity: | Up to 100 CD-ROM discs |
| Configurations: | One or Four readers or two readers and one writer |
| Disc Swap Time: | Less than six seconds |
| Disc Load Time: | Less than three seconds |
| Reader/Writer Interfaces: | SCSI-2 active termination |
| Changer Interface: | SCSI-2 (single-ended) |
| Platform Support: | DOS, Windows 95, Windows 3.1 and Windows NT, Macintosh, OS/2, Novell, UNIX, HP, DEC ODF/Alpha, Sun OS and Solaris. |
| Software Drivers: | Software support available from third-party vendors |
| Dimensions (W x H x D): |
10 �" x 19" x 23" |
| Mean Swaps Between Failure: | 1,000,000 Swaps |
|
DRM-5004X CD-ROM Library - A 500-disc,
near on-line CD-ROM storage system, the DRM-5004X is a cost efficient answer to your high
capacity archival needs. It is ideal for information management offering a multitude of
imaging and archival applications. The DRM-5004X stores up to 320 GB of total data
including text, video, audio, or graphics. SRP starting at $14,995 |
| Product Name: | DRM-5004X |
| Brief Description: | A 500-disc, near on-line optical storage system, the DRM-5004X is a cost-efficient solution to high capacity archival data storage. It is ideal for a variety of imaging and high-capacity archival applications storing up to 320 Gbytes of total data. The DRM-5004X can be configured with any combination of read or write drives up to four total drives. It includes five removable 100-disc magazines and can be locked for added security of data. Popular markets utilize the DRM-5004X for a variety of archival and imaging applications including libraries, government, banking and finance, legal, medical and military. |
| Features: | -Reliable access
to 500 CD-ROM discs. -Can be configured with any combination of 4X readers or writers. -Features five removable 100-disc magazines. -User-friendly keypad and display. -Lockable front door for securing data. |
| Specifications: | |
| Disc Capacity: | Up to 500 CD-ROM discs |
| Configurations: | Any combination of 4X readers or writers (up to four drives). |
| Disc Change Time: | 18 Seconds |
| Sustained Data Transfer Rate: | 614 Kbytes/second (reader); 614 Kbytes/second (writer mode 1, mode 2, form 1) and 701 Kbytes/second (mode 2, form 2). |
| Reader/Writer Interfaces: | SCSI-2 active termination |
| Changer Interface: | SCSI-2 (single ended) |
| Platform Support: | DOS, Windows 95, Windows 3.1 and Windows NT, Macintosh, OS/2, Novell, UNIX, HP, DEC ODF/Alpha, Sun OS and Solaris, AIX. |
| Software Drivers: | Available from third party vendors. |
| Dimensions (W x H x D): |
17-13/16" x 45-5/8" x 19-15/16" |
| Mean Swaps Between Failure: | 1,000,000 Swaps |
| CD/DVD | ||||
| Model | Max. Capacity | # of Drives | Supported Media | Warranty* |
| D-120 | 78GB | 2 or 4 | CD-ROM, CD-R, and CD/RW | One Year Parts and Labor |
| D-240 | 156GB | 2, 4 or 6 | CD-ROM, CD-R, and CD/RW | One Year Parts and Labor |
| D-480 | 312GB | 2, 4 or 6 | CD-ROM, CD-R, and CD/RW | One Year Parts and Labor |
| D-120DR | 312GB | 2 or 4 | CD-ROM, CD-R, CD/RW, DVD-ROM, DVD-R, and DVD-RAM | One Year Parts and Labor |
| D-240DR | 624GB | 2, 4 or 6 | CD-ROM, CD-R, CD/RW, DVD-ROM, DVD-R, and DVD-RAM | One Year Parts and Labor |
| D-480DR | 1.2TB | 2, 4 or 6 | CD-ROM, CD-R, CD/RW, DVD-ROM, DVD-R, and DVD-RAM | One Year Parts and Labor |
| *On-site service can be purchased for all CD and DVD-RAM jukeboxes. | ||||
|
100 Disc CD-ROM Desktop Library with 2 (12X) CD- ROM drives. Ideal for Single Users and Small Workgroups. Comes with SmartCD Neighborhood for Windows 95 & NT software. | 100 Disc CD-ROM Desktop Library with 2
(12X) CD-ROM drives. Ideal for Windows NT� Networks. Bundle includes SmartCD
Access Software for Windows NT . |
100 Disc CD-ROM Desktop Library with 2 (12X) CD- ROM drives. Ideal library for Macintosh� Networks. The bundle includes Astarte Miles Apart for MacOS� |
| Model Number | CDL-1100-20 |
CDL-1100-22 |
CDL-1100-23 |
| List Price | $2,995 | $3,639 | $3,639 |
| Max. No. Drives | 2 CD-ROM | 2 CD-ROM | 2 CD-ROM |
| Max. No. Discs | 100 | 100 | 100 |
| Sustained Transfer Rate | 1160 to 1800 kB/s | 1160 to 1800 kB/s | 1160 to 1800 kB/s |
| Access Time | 130 ms | 130 ms | 130 ms |
| Disc Exchange Time | 12.2 s | 12.2 s | 12.2 s |
| Buffer Memory | 64 kB (Drive) | 64 kB (Drive) | 64 kB (Drive) |
| Interface | SCSI-2 Fast, Single-ended | SCSI-2 Fast, Single-ended | SCSI-2 Fast, Single-ended |
| Analog Audio Output | Stereo mini jack | Stereo mini jack | Stereo mini jack |
| Library Diagnostics | RS-232C D-Sub 9-Pin | RS-232C D-Sub 9-Pin | RS-232C D-Sub 9-Pin |
| Disc Loading | Motorized mailslot tray | Motorized mailslot tray | Motorized mailslot tray |
| Disc Transport | Caddyless picker mechanism | Caddyless picker mechanism | Caddyless picker mechanism |
| MTBF | 40,000 POH | 40,000 POH | 40,000 POH |
| MSBF | 100,000 Cycles | 100,000 Cycles | 100,000 Cycles |
| MTTR | 30 Minutes | 30 Minutes | 30 Minutes |
| Readable Disc Formats | CD-Digital Audio, CD Extra CD-ROM (Mode 1 & 2) CD-ROM XA (Mode 2 Form 1 & 2) CD-I Ready* Photo CD (Single and multiple session) CD-Bridge, Video CD |
CD-Digital Audio, CD Extra CD-ROM (Mode 1 & 2) CD-ROM XA (Mode 2 Form 1 & 2) CD-I Ready* Photo CD (Single and multiple session) CD-Bridge, Video CD |
CD-Digital Audio, CD Extra CD-ROM (Mode 1 & 2) CD-ROM XA (Mode 2 Form 1 & 2) CD-I Ready* Photo CD (Single and multiple session) CD-Bridge, Video CD |
| Dimensions (WxHxD) | 8.46 x 16.9 x 17.13 inches | 8.46 x 16.9 x 17.13 inches | 8.46 x 16.9 x 17.13 inches |
| Weight | 13 lb 12 oz | 13 lb 12 oz | 13 lb 12 oz |
| Accessories Included | SmartCD Neighborhood for Windows 95 & NT |
SmartCD Access Software for Windows NT |
Astarte Miles Apart for MacOS� |
