The first thing you are going to do is remove the dash trim which is located at my indiglo gauge install Dash trim removal. Once you have all the screws out there are still 2 connectors and 1 cable connected to it. Unplug the 2 connectors and for the cable there is a screw holding it secure which you will need to unscrew then slide the ring off the white rod. Now you will be able to completly remove the dash trim. Once you have the dash trim out its time to remove the circut board with all the LED's you will be replacing.
There are 5 gold screws holding the black top to the circuit board and once you have that off there is 1 more gold screw holding the circuit board. Here is what the circuit board looks like when you have completly removed it. I have circled in blue the LED's that are to be removed and replaced with blue ones.
Now to take the circuit board out you just have to rock each side back and forth. There is a set of wires leading to a bulb that you can twist and pop out so you can completly remove the circuit board.
|
