- Displacement: Tons: 3,250 standard; 3,730 full load
- Dimensions: Ft: 433.1 x 42 x 15.3
- Main machinery: 2 boilers; 2 turbines; 72,000-hp (m) (53 MW); 2 shafts
- Speed: Knots: 32
- Range: Miles: 2,970 at 18 kt
- Complement: 280 (45 officers)
SSM: 8 YJ-1 (Eagle Strike) (C-801) (CSS-N-4 Sardine) (4 twin) launchers [Ref 1]
active radar homing to 40 km (22 n miles) at 0.9 Mach
warhead 165 kg; sea-skimmer.
SAM: LY 60N in due course. A/S: The after set of launchers may also be used for CY-1 Anti-submarine missiles; range 8-15 km (4.4-8.3 n miles).
4 USSR 5.1 in (130 mm)/58 (2 twin) [Ref 2]; 85°elevation; 17 rds/min to 29 km (16 n miles); weight of shell 33.4 kg.
8 China 37 mm/63 (4 twin) [Ref 3]; 85° elevation; 180 rds/min to 8.5 km (4.6 n miles); weight of shell 1.42 kg.
6 - 324 mm Whitehead B515 (2 triple tubes) [Ref 4];
Yu-2 (Mk 46 Mod 1); active/passive homing to 11 km (5.9 n miles) at 40 kt; warhead 44 kg.
A/S MORTARS: 2 FQF 2500 12-tubed fixed launchers [Ref 5]; 120 rockets; range 1,200 m; warhead 34 kg. Similar in design to the RBU 1200.
Decoys: 2 - 15 tubed fixed launchers for chaff
and IR decoys.
ESM: Jug Pair (RW-23-1); radar warning.
Air search: Rice Screen 3D; G-band. Similar to Hughes SPS-39A.
Surface search: China ESR 1 I-band.
Navigation: Racal Decca 1290; I-band.
Fire control: Type 343 Sun Visor B G/H-band.
IFF: High Pole.
Hull-mounted; active search and attack;
medium frequency.
VDS; active search and attack; medium frequency.
Updated Luda design. Possibly now in series production but there may be confusion with more of the "Luhu" class.
Modified after SSM launchers which may fire the CY-1 anti-submarine missile and the LY 60N SAM in due course.
South Seas Fleet based at Zhanjiang. There have long been reports of a ballistic trajectory ASW weapon CY-1 and the different types of SSM launchers in Zhuhai indicate that the weapon may now be operational. Different pennant number used for foreign deployments.
