Download schematics for the 111 Type 2.
Selector
RF Amplifier
Power converter
Speaker
Tubes
Service Notes
There appear to have been two slightly different versions of the 111 chassis, which differ only in the construction of the power converter. Type 1 models had an additional resistor and capacitor in the power converter circuit (R15 and C19), and differ in a few internal connections.
The RF Amplifier unit is the same as that found in most models (ie. 931 type). The tuning selector unit is also of the 931 type, and is shared by several other models. The Model 110 and 111 differ from the 111-A which was slightly more luxurious and used the tuning selector with the additional 484 tube. The power converter unit of the 111-A also has some minor differences from that of the 110 and 111.
