The Simplest C
Program Let's start with the simplest possible
C program and use it both to understand the basics of C
and the C compilation process. Type the following
program into a standard text editor (vi or emacs on
UNIX, Notepad on Windows or TeachText on a Macintosh).
Then save the program to a file named samp.c. If
you leave off .c, you will probably get some sort
of error when you compile it, so make sure you remember
the .c. Also, make sure that your editor does not
automatically append some extra characters (such as
.txt) to the name of the file. Here's the first program:
#include <stdio.h>
int main()
{
printf("This is output from my first program!\n");
return 0;
}
When executed, this program instructs the computer to
print out the line "This is output from my first
program!" -- then the program quits. You can't get much
simpler than that!
Position
When you enter this program,
position #include
so that the pound sign is in column 1 (the far
left side). Otherwise, the spacing and indentation
can be any way you like it. On some UNIX systems,
you will find a program called cb, the C
Beautifier, which will format code for you. The
spacing and indentation shown above is a good
example to follow.
|
To compile this code, take the following steps:
- On a UNIX machine, type gcc samp.c -o samp
(if gcc does not work, try cc). This line invokes the
C compiler called gcc, asks it to compile samp.c and
asks it to place the executable file it creates under
the name samp. To run the program, type
samp (or, on some UNIX machines,
./samp).
- On a DOS or Windows machine using DJGPP, at an
MS-DOS prompt type gcc samp.c -o samp.exe. This
line invokes the C compiler called gcc, asks it to
compile samp.c and asks it to place the executable
file it creates under the name samp.exe. To run
the program, type samp.
- If you are working with some other compiler or
development system, read and follow the directions for
the compiler you are using to compile and execute the
program.
You should see the output "This is output from my
first program!" when you run the program. Here is what
happened when you compiled the program:
If you mistype the program, it either will not
compile or it will not run. If the program does not
compile or does not run correctly, edit it again and see
where you went wrong in your typing. Fix the error and
try again.
Let's walk through this program and start to see what
the different lines are doing:
- This C program starts with #include <stdio.h>. This
line includes the "standard I/O library" into
your program. The standard I/O library lets you read
input from the keyboard (called "standard in"), write
output to the screen (called "standard out"), process
text files stored on the disk, and so on. It is an
extremely useful library. C has a large number of
standard libraries like stdio, including string, time
and math libraries. A library is simply a
package of code that someone else has written to make
your life easier (we'll discuss libraries a bit
later).
- The line int main()
declares the main function. Every C program must have
a function named main somewhere in the code. We
will learn more about functions shortly. At run time,
program execution starts at the first line of the main
function.
- In C, the { and
} symbols mark the
beginning and end of a block of code. In this case,
the block of code making up the main function contains
two lines.
- The printf
statement in C allows you to send output to standard
out (for us, the screen). The portion in quotes is
called the format string and describes how the
data is to be formatted when printed. The format
string can contain string literals such as "This is
output from my first program!," symbols for carriage
returns (\n), and operators as
placeholders for variables (see below). If you are
using UNIX, you can type man 3 printf to get
complete documentation for the printf function. If
not, see the documentation included with your compiler
for details about the printf function.
- The return 0; line
causes the function to return an error code of 0 (no
error) to the shell that started execution. More on
this capability a bit later.
Variables
As a programmer, you will
frequently want your program to "remember" a
value. For example, if your program requests a
value from the user, or if it calculates a value,
you will want to remember it somewhere so you can
use it later. The way your program remembers
things is by using variables. For
example:
int b;
This line says, "I want to create
a space called b that is able to hold one integer
value." A variable has a name (in this
case, b) and a type
(in this case, int, an
integer). You can store a value in b by saying
something like:
b = 5;
You can use the value in b by
saying something like:
printf("%d", b);
In C, there are several standard
types for variables:
- int - integer
(whole number) values
- float -
floating point values
- char - single
character values (such as "m" or "Z")
We will see examples of these other types as we
go along.
|
Here is another program that will help you learn more
about printf:
#include <stdio.h>
int main()
{
int a, b, c;
a = 5;
b = 7;
c = a + b;
printf("%d + %d = %d\n", a, b, c);
return 0;
}
Type this program into a file and save it as
add.c. Compile it with the line gcc add.c -o
add and then run it by typing add (or
./add). You will see the line "5 + 7 = 12" as
output.
Here is an explanation of the different lines in this
program:
- The line int a, b,
c; declares three integer variables named
a, b and c. Integer variables
hold whole numbers.
- The next line initializes the variable named
a to the value 5.
- The next line sets b to 7.
- The next line adds a and b and
"assigns" the result to c.
The computer adds the value in a (5) to the
value in b (7) to form the result 12, and then
places that new value (12) into the variable c.
The variable c is assigned the value 12. For
this reason, the = in this
line is called "the assignment operator."
- The printf
statement then prints the line "5 + 7 = 12." The %d placeholders in the printf
statement act as placeholders for values. There are
three %d placeholders, and at the end of the printf
line there are the three variable names: a, b and c. C matches up the first %d with a
and substitutes 5 there. It matches the second %d with b
and substitutes 7. It matches the third %d with c
and substitutes 12. Then it prints the completed line
to the screen: 5 + 7 = 12. The +, the = and the spacing are a part
of the format line and get embedded automatically
between the %d operators as specified by the
programmer.
This program is good, but it would be better if it
read in the values 5 and 7 from the user instead of
using constants. Try this program instead:
#include <stdio.h>
int main()
{
int a, b, c;
printf("Enter the first value:");
scanf("%d", &a);
printf("Enter the second value:");
scanf("%d", &b);
c = a + b;
printf("%d + %d = %d\n", a, b, c);
return 0;
}
Here's how this program works when you execute it:
Make the changes, then compile and run the program to
make sure it works. Note that scanf uses the same sort of format
string as printf (type man
scanf for more info). Also note the & in front of a and b. This
is the address operator in C: It returns the
address of the variable (this will not make sense until
we discuss pointers). You must use the & operator in
scanf on any variable of type char, int, or float, as
well as structure types (which we will get to shortly).
If you leave out the & operator, you will get an
error when you run the program. Try it so that you can
see what that sort of run-time error looks like.
How printf Works The printf statement allows
you to send output to standard out. For us, standard
out is generally the screen (although you can redirect
standard out into a text file or another command). Let's
look at some variations to understand printf completely.
Here is the simplest printf statement:
printf("Hello");
This call to printf has a format string that tells
printf to send the word "Hello" to standard out.
Contrast it with this:
printf("Hello\n");
The difference between the two is that the second
version sends the word "Hello" followed by a carriage
return to standard out.
The following line shows how to output the value
of a variable using printf.
printf("%d", b);
The %d is a
placeholder that will be replaced by the value of the
variable b when the
printf statement is executed. Often, you will want to
embed the value within some other words. One way to
accomplish that is like this:
printf("The temperature is ");
printf("%d", b);
printf(" degrees\n");
An easier way is to say this:
printf("The temperature is %d degrees\n", b);
You can also use multiple %d placeholders in one
printf statement:
printf("%d + %d = %d\n", a, b, c);
In the printf statement, it is extremely important
that the number of operators in the format string
corresponds exactly with the number and type of the
variables following it. For example, if the format
string contains three %d operators, then it must be
followed by exactly three parameters and they must have
the same types in the same order as those specified by
the operators.
You can print all of the normal C types with
printf by using different placeholders:
- int (integer
values) uses %d
- float (floating
point values) uses %f
- char (single
character values) uses %c
- character strings
(arrays of characters, discussed later) use %s
You can learn more about the nuances of printf on a
UNIX machine by typing man 3 printf. Any other C
compiler you are using will probably come with a manual
or a help file that contains a description of printf.
How scanf Works The scanf function allows you
to accept input from standard in, which for us is
generally the keyboard. The scanf function can do a lot
of different things, but it is generally unreliable
unless used in the simplest ways. It is unreliable
because it does not handle human errors very well. But
for simple programs it is good enough and easy-to-use.
The simplest application of scanf looks like this:
scanf("%d", &b);
The program will read in an integer value that the
user enters on the keyboard (%d is for integers, as is
printf, so b must be declared as an int) and place that
value into b. The scanf function uses the same
placeholders as printf:
- int uses %d
- float uses %f
- char uses %c
- character strings (discussed later) use
%s
You MUST put & in
front of the variable used in scanf. The reason why will
become clear once you learn about pointers. It is
easy to forget the & sign, and when you forget it
your program will almost always crash when you run it.
In general, it is best to use scanf as shown here --
to read a single value from the keyboard. Use multiple
calls to scanf to read multiple values. In any real
program, you will use the gets or fgets functions instead to read
text a line at a time. Then you will "parse" the line to
read its values. The reason that you do that is so you
can detect errors in the input and handle them as you
see fit.
From this discussion, you can see that it is very
easy to create simple C programs. The printf and scanf
functions will take a bit of practice to be completely
understood, but once mastered they are extremely useful.
Previous 1 . 2 . 3 . 4 Next
|
