Observations of the planets is perhaps the most difficult area for the amateur astronomer to achieve good results. The primary source of this difficulty is of course due to atmospheric turbulence. Due to their small angular sizes, high magnifications are required to make surface detail visible. Unfortunately, small and large scale motion in the air is magnified as well. Pockets of air with different densities cause the telescopic image to move in and out of focus, blurring the view. Interspersed with these periods of poor seeing, are brief intervals of clarity, when the planet can appear to suddenly pop into sharp focus. It is in these spells of good seeing, that the observer is able to record planetary markings. |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Below are sketches of Mars made during three different apparitions of the planet. The first two were made in 1990, using the 8 inch Celestron telescope, with a magnification of 303 X. The far right drawing was made in 1993 at a magnification of 225 X. The color differences between the two sets is subjective, the redness in the later image being exagerrated, possibly due to a contrast effect from the prominent polar cap. |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
February 9, 1993 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
December 11. 1990 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
November 7, 1990 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
The key to successful planetary observing is practice. Although markings are often subtle and difficult to perceive clearly, the eye -brain system will learn to discern detail better with repeated viewing. Familiarity with a planet's features will tend to reveal finer details that went unnoticed at first. These drawings are really integrations of the moments of good seeing, those few seconds when things come into sharp focus. A min- imum of fifteen minutes viewing time would be typical for each drawing. |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
January 30, 1995 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
February 26, 1995 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Jupiter, even though further out than Mars, will always show some degree of detail due to its greater size. The features we see on Jupiter are cloud tops or atmospheric storms, any surface is completely obscured. The two most prominent features on the drawing at left are the north and south equatorial belts. These are obvious even in small telescopes. In moments of good seeing, far more detail would be visible in these belts than is shown here. Also obvious in binoculars or a small telescope are Jupiter's four brightest moons. The positions of the moons changes completely from night to night, motion can indeed be seen during the course of an observing session. At times one or more will cross in front of the planet, and a transit, takes place. At left a moon is shown near the right edge, or limb, of the planet. The black circle serves to indicate the satellite for purposes of the drawing, in reality the moon appeared as a bright spot against Jupiter. When properly positioned with the sun, a moon transiting Jupiter will cast a distinct shadow on the cloud tops, as in the lower drawing. |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
March 11, 1991 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Another prominent feature is the Great Red Spot. It is seen in the drawing at left as a bulge in the South Equatorial Belt. (south is at the top in both drawings, matching the telescopic view) A product of atmospheric turbulence roughly the size of the earth, the Red Spot revolves in a counterclockwise direction every six days. Jupiter itself completes a rotation in just under 10 hours, producing the oblate shape and allowing positional changes to be seen on short time scales. Numerous other belts and lighter zones are regularly seen, the level of detail increasing with scope size and improved seeing. |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
May 8, 1993 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Saturn, like Jupiter, also displays a system of belts. Yellowish-brown in color, they lack the detail and distinctiveness of those on the larger planet. White spots or ovals occasionally appear, these are thought to be eruptions of gas from the lower atmosphere. The most outstanding feature of the planet is of course the ring system. Easily visible in small telescopes, even the casual observer will find them an awesome sight. Three primary rings are discernable in amateur scopes. The outer, or A Ring, is separated from the B Ring by the Cassini Division. This dark area is shown partially resolved in the drawing at left. The A Ring itself is split by the Encke Division, a finer and more difficult feature. Good seeing and a six to eight inch telescope is usually required to see it. The B Ring is the widest and brightest. Detail is sometimes observed here as concentric lines, or radial shadings, called spokes, but these are difficult to see without optimal conditions. The innermost, or Crepe Ring, is much fainter, best seen against the planet itself. Otherwise it tends to fade into the dark sky background. The orientation of the rings changes regularly over time, appearing edge on every 13.7 or 15.5 years. When this occurs, they disappear from view in even the largest telescopes. The lower left drawing shows their appearance three weeks after the earth passed through the ring plane in 1995. |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
August 7, 1991 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
August 31, 1995 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
