The Parts of Adobe Photoshop

The Menu bar

The menu bar consists of nine menus: File, Edit, Image, Layer, Select, Filter, View, Window, and Help. Take a few moments now to look at each of the menus. You may notice that some menu commands are followed by ellipses (...). This indicates a command that is followed by a dialog box where you can enter additional settings. Some menu commands are followed by a right pointing arrow. This indicates a submenu of related commands. As you explore each menu, be sure to take a look at the submenus as well. You'll also notice that many commands are followed by keyboard shortcuts. Gradually, you'll want to get to know these keyboard shortcuts as they can be incredible time savers.
As we make our way through this course, we'll be learning the most useful keyboard shortcuts as we go along.
In addition to the menu bar, Photoshop often has context sensitive menus for accessing some of the most likely commands depending on which tool is selected and where you click. You access the context sensitive menu by right clicking in Windows, or pressing the Control key on a Macintosh.
One of the most convenient contextual menus can be accessed by right clicking/Control clicking on the title bar of a document for quick access to the duplicate command, image and canvas size dialogs, file information, and page setup. If you already know how to open an image, go ahead and try it now. Otherwise, you'll learn how in the next section.



The Toolbox

Now let's explore more of the Photoshop toolbox. If you have the Quick Reference Card that came with Photoshop, it would be a good idea to locate it now. If you cannot locate a copy, Version 6.0 users can find a PDF file of the Quick Reference card on the main level of your Photoshop installation CD. Version 5.x users can find a diagram of the toolbox and all hidden tools on page 25 of the Photoshop 5.0 User Guide.
When you look at the toolbox, notice how some of the buttons have a tiny arrow in the lower right corner. This arrow indicates that other tools are hidden under that tool. To access the other tools, click and hold down on a button and the other tools will pop out. Try this now by clicking on the rectangle marquee tool and changing to the elliptical marquee tool. The hidden marquee tools are shown here.
Now hold your cursor over one of the buttons and you should see a tooltip appear that tells you the name of the tool and its keyboard shortcut. All the marquee tools have a shortcut of M. An easier way to switch between the different hidden tools is to use the keyboard shortcut along with the Shift key modifier. For the marquee tools, theShift-M combination toggles between the rectangular and elliptical marquee tools. The single row marquee tools are less often used and must be selected from the toolbox flyout. Another shortcut for cycling through the hidden tools is to Alt/Option click on the toolbox button.
Take a few moments now to familiarize yourself with the tool names using the tooltips. Use the shortcuts you've just learned to explore all the hidden tools. As you select each tool, note the hints provided in the status bar area for each tool. Don't worry about using each tool for now; we'll get to that soon enough. For now, you should just get to know the tool locations and their icons.
Moving down in the toolbox, we come to the color swatches. This is where the foreground and background colors are displayed. The tiny arrow to the top right allows you to swap foreground and background colors. The tiny black and white swatch symbol to the lower left allows you to reset the colors to the default of black foreground and white background. Hold your cursor over those two areas to learn the keyboard shortcuts. To change a color, simply click on either the foreground or background color swatch and select a new color in the color picker. Experiment by changing the foreground and background colors and then resetting them back to defaults.
The next two buttons on the toolbox allow you to toggle between quick mask and selection mode. We'll learn more about this later in future lessons.
Below that you have a set of three buttons that allow you to change the appearance of the workspace. Hold your cursor over each button to see what it does. Notice the keyboard shortcut for all three is F. Hitting F repeatedly toggles between all three modes. Try it now.
This is a convenient place to mention a few more shortcuts for modifying the workspace appearance. Feel free to try them out as you read. When in either of the full screen modes, you can toggle the menu bar on and off with the Shift-F key combination. In any screen mode you can toggle the toolbox, status bar, and palettes on and off with the Tab key. To hide only palettes and leave the toolbox visible, use Shift-Tab. The last button on the toolbox is for moving your document to ImageReady. We will not be exploring ImageReady in this course.
Before we move on to the palettes, let's review what we learned about the toolbox:

1. An arrow indicates a flyout of hidden tools.
2. Each main tool has a single letter keyboard shortcut assigned to it.
3. The Shift key combined with a tool shortcut allows you to toggle the hidden tools.
4. D = resets the foreground color to black and background color to white.
5. X = swap foreground and background colors.
6. F = toggles screen modes
7. Shift-F = Turns menu bar on and off in full screen modes 8. Tab = toggles the toolbox, status bar, and palettes on and off
9. Shift-Tab = toggle only the palettes on and off
The Navigator Palette grouped with the info and Options Palettes.


The Palettes

When you first open Photoshop, the palettes are stacked along the right edge of your screen in palette groups. The first group contains the Navigator, Info, and Options palettes. Next is the Color Swatches, and Brushes palettes. Below that are the History and Actions Palettes. Finally, you have the Layers, Channels, and Paths Palettes.
Palette groups can be moved around in the workspace by clicking on the title bar and dragging. Each palette group has a collapse and a close button in the title bar area. Try the collapse button for each of the palette groups now. You'll notice the button works as a toggle, clicking the button a second time after the palette is collapsed will expand the palette again. You may also notice that some palettes do not completely collapse. Try collapsing the color palettes and you'll see that the color ramp is still visible.
For palettes that partially collapse, you can completely collapse them by holding down theAlt/Option key as you press the collapse button. You can also collapse a group by double clicking on any of the palette tabs. To display a collapsed palette, just click once on the palette tab if it's in the back of the group, or double click if it's in the front of the group.
Palettes can be resized either by holding your cursor over an edge and dragging when the cursor changes to a double pointing arrow, or by clicking and dragging on the right corner. Only the Color, Options, and Info palettes are not resizable.
When you click the close button on a palette group it closes all the palettes in the group. To display a palette that is not shown, you can either choose the command from the Window Menu, or display the palette using its keyboard shortcut. They are:

� Enter or Return = Show/Hide Options Palette (V5.x only)
� Double click tool button = Show/Hide Options Palette (V5.x only)
� F5 = Show/Hide Brushes Palette
� F6 = Show/Hide Color Palette
� F7 = Show/Hide Layers Palette
� F8 = Show/Hide Info Palette
� F9 = Show/Hide Actions Palette
And don't forget these which we learned in the last lesson:

� Tab = Show/Hide Toolbar and all Palettes
� Shift-Tab = Show/Hide all Palettes

To bring a grouped palette to the front of the group, click on the palette's tab. You can also ungroup and rearrange the palettes by clicking on a tab and dragging it outside of the group or to another group. Try it now by dragging the navigator palette out of it's default group. Then put it back by dragging it back onto the palette group.
