This basic setup is used for teaching fundamentals of data acquisition and signal processing to UG and PG students. The data acquisition system consists of a 5 MHz sampling frequency analog to digital conversion card from National Instruments. The driver software is based on LabVIEW programming language. Pre-recorded machinery signals on a DAT recorder can be acquired and analyzed with this system, which consists of simultaneous 8 channel sampling. Other A/D cards with lower sampling rates of 333 kHz and 50 kHz are also available.

	10. DATA ACQUISITION AND SIGNAL PROCESSING SETUP



	This basic setup is used for teaching fundamentals of data acquisition and signal processing to UG and PG students. The data acquisition system consists of a 5 MHz sampling frequency analog to digital conversion card from National Instruments. The driver software is based on LabVIEW programming language. Pre-recorded machinery signals on a DAT recorder can be acquired and analyzed with this system, which consists of simultaneous 8 channel sampling. Other A/D cards with lower sampling rates of 333 kHz and 50 kHz are also available.
