 All
simulators use one of two IVEX VDS-1000STS/500 Out-the-Window Display systems.
One single-channel scene generator provides a 45- by 36-degree field of
view while a two-channel generator provides a 90- by 36-degree field of
view. Using curved projection screens adds a greater sense of realism to
the simulations. We have a proven history and we
offer a wide variety of products and services.
At TEMS we help train America's pilot's and
prove the technologies of the future. We strive
continuously to improve the test process and have several planned
upgrades.
Three Real-Time Image Generators and Simulation Complexes
Simulators
- F-16A/B High Fidelity with 120 Degree visual
- C-17 Medium-Fidelity with 90 Degree Visual
- F-15 Low-Fidelity with 40 Degree Visual
- DEC VAX 6000 Computers
- Migrating to SGI ONYX Computers
Products & Services
- Fifteen 8-channel stripchart recorders
- Ridley Mission Control Center Data Displays
- Real-time simulation data viewer
- Data Login of all simulation parameters
- Analysis Tool Suite
- Parameter Estimations (PEST)
- Frequency Response Analysis (FRA)
- Flight control system analysis software (MATLAB/Simulink)
- Simulation data validation analysis software (PV-WAVE)
- Walk Away Data Products
History
- Simulation Facility Created in 1950s
- Evolution from Analog to Digital Simulations
- Supported Research and Production Programs
- X-2, X-15A, X-24A/B,
- Space Shuttle
- F-16A-D, AFTI/F-16
- F-15, F-15 (STOL)
- B-1B
- C-17
- Engineering Simulation Supporting Performance and Flight Qualities
- Expanded to Support Electronic Warfare
Current Programs
Planned Upgrades
- J-MASS real-time warfare environment and suppressor missions
- Simulated warfare environment generator - mission level
- Expanded visual database support for high speed corridor testing
- Four-ship air warfare mission simulator
