Equipment

6/05/02 Installed Mega ACn 22/20/3 Brushless Jeti Jes 40 with BEC
1 Tower Servo TS-31 Elevator 1 Multiplex CB688 Servo Rudder
2 HiTec HS 81 servo's ailerons Hitec 555 RX
8 Nicads
Kavan 11 X 7.75 prop or APC 11 X 7

Specifications
40" Wing 515 sq. in.
48" Wing 620 sq. in.
Covered with Polyester & Dope, Tail Feathers removable
40" Weight RTF 54.6 oz. 6/05/02 53.8 oz.
48" Weight RTF 55.8 oz. 8/7/04
Incidence - Wing + 3.0, motor -1.0 8/7/04

Modifications
48" wing converted to Ailerons, same specs as 40"
Torsion bar landing Gear 3 ½" mains
Steerable Radio-Active tail wheel
Battery Ejectable through windshield, Enclosed motor with top hatch
Increased L/G wire size to 1/8"

CS Throws R - ½ E - ½ A - ¾ U ¾ D

In Service RTF 11/99
*****************************
8/7/04
Converted to TP 3S3P Li-Po 6000 mah battery
Changed ESC to Jeti Advance 40-3P with Lithium Support
*****************************
9/29/04 Run Up SV 12.1 A 25.7 W 290 - Computed 14 Minutes Full Throttle
RTF 9/29/04
