Developing Software Solutions
Formatting output
Interactive
Strings
Example 2.1
All programs "declare
variables"; in this the variables are REAL (not integers or Boolean ..true
or false). The last END must have a fullstop. Note the equals sign := and the
multiplication *. Write(Apples) and
Writeln(Apples) give the answer but writeln goes to the next line after it has
written the answer.
Type in the following program
PROGRAM
Multiplication;
VAR
Apples, Pears, Bananas:real;
BEGIN
Pears:=0.002;
Bananas:=4700;
Apples:=Pears*Bananas;
Writeln(Apples)
END.
The
output produced by the program is
9.4000000000E+00
Example 2.2
Words can be printed as well as
number in the answer using apostrophes ' in writeln statements.
PROGRAM
Multiplication;
VAR
Apples, Pears, Bananas:real;
BEGIN
Writeln('This program will multiply
two numbers together');
Pears:=0.002;
Bananas:=4700;
Writeln('The first number is
',Pears);
Writeln('The second number is
',Bananas);
Apples:=Pears*Bananas;
Writeln;
Writeln('The product is ',Apples)
END.
Example 2.3
This example shows how to
"SPACE OUT" your answers across the screen. Modify example 2 and include these extra lines
Clrscr;
Writeln;
Writeln;
Writeln;
Writeln(' FIRST No':20,'SECOND
No':20,'PRODUCT':20);
Writeln('--------':20,'---------':20,'-------':20);
Example 2.4
We start to "FORMAT" the output
so that it is readable
eg Apples:20 means that it takes up
20 spaces
PROGRAM
Multiplication;
VAR
Apples, Pears, Bananas:real;
BEGIN
Clrscr;
Writeln;
Writeln;
Writeln;
Writeln(' FIRST No':20,'SECOND
No':20,'PRODUCT':20);
Writeln('--------':20,'---------':20,'-------':20);
Pears:=0.0015;
Bananas:=1000;
Apples:=Pears*Bananas;
Writeln(Pears:20,Bananas:20,Apples:20)
END.
OUTPUT
is .....
Example 2.5
A further "FORMAT" is
Pears:20:4 where 4 gives
the number of decimal places to show
Modify
the program with this :4.
OUTPUT
is......
Example 2.6
This is an example of an
"interactive" program. The program stops; asks you a question and
waits for an answer.
PROGRAM
Multiplication;
VAR
Apples, Pears, Bananas:real;
BEGIN
Clrscr;
Writeln('This program calculates the
product of the two numbers entered');
Writeln('Enter the first number');
Readln(Pears);
Writeln('Enter the second number');
Readln(Bananas);
Writeln;
Writeln(' FIRST No':20,'SECOND
No':20,'PRODUCT':20);
Writeln('--------':20,'---------':20,'-------':20);
Apples:=Pears*Bananas;
Writeln(Pears:20,Bananas:20,Apples:20)
END.
Exercise 2.7
Write
a program for Task 1.3. It is to be handwritten on A4 paper.
This is due 21st February
Make your programs user friendly
Example 2.8
PROGRAM
TestAverage;
VAR
StudentName : STRING[30];
CourseName : STRING[30];
Score1, Score2, Score3, Score4,
Average: real;
BEGIN
Clrscr;
Writeln('This program will calculate
the average of four')
Writeln('test scores that you
emter.');
Writeln;
Writeln;
Writeln;
Write('Enter the student name: Name=
');
Readln(StudentName);
Writeln;
Write('Enter the course name:
Course= ');
Writeln;
Write('Enter the first test score:
Test #1 = ');
Readln(Score1);
Writeln;
Write('Enter the second test score:
Test #2 = ');
Readln(Score2);
Writeln;
Write('Enter the third test score:
Test #3 = ');
Readln(Score3);
Writeln;
Write ('Enter the fourth test score:
Test #4 = ');
Readln(Score4);
Average:=(Score1+Score2+Score3+Score4)/4;
Writeln;
Writeln;
Writeln;
Writeln ('Student Name: ',StudentName);
Writeln;
Writeln('Course: ',CourseName);
Writeln;
Writeln('Test #1':10,'Test
#2':10;'Test #3':10,'Test #4':10,'Average':10);
Writeln('-------':10,'-------':10,'-------':10,'-------':10,'-------':10,);
Writeln;
Writeln(Score1:10:2,Score2:10:2,Score3:10:2,Score4:10:2,Average:10:2);
END.
