BLOHM und VOSS BV-141

Behold... The ONE and ONLY BV.141... This type is too well known to describe it one more time. Just type "BV+141" in your favorite Web Search browser and get A LONG LIST of sites and pages devoted to this outstanding aircraft.

Type: Tactical Reconnaissance / Light Bomber

Engine:
(A) 960hp BMW 132N nine-cylinder radial
(B) 1,560hp BMW 801A 14-cylinder two-row radial

Dimensions:
Wing span:
(A) 15.44m (50ft 8.25in)
(B) 17.46m (57ft 3.25in)

Length:
(A) 9.96m (39ft 10.25in)
(B) 13.95m (45ft 9.25in)

Height:
(A) 4.10m (13ft 5.5in)
(B) 11ft 9.75in)

Weights:
Empty:
(A) 3,167kg (6,982 lbs.)
(B) 4,700kg (10,363 lbs.)

Loaded:
(A) 3,900kg (8,598 lbs.)
(B) 5,700kg (12,568 lbs.)

Performance:
Maximum Speed:
(A) 248 mph (400 kph)
(B) 272 mph (438 kph)

Range:
(A) 1,139km (708 miles)
(B) 1,900km (1,180 miles)

Service Ceiling:
10,000m

Armament:
Two fixed 7.92mm MG 17 forward firing machine guns
One manually aimed 7.92mm MG 15 mounted in the dorsal bubble
One manually aimed 7.92mm MG 15 mounted in the tailcone
Four 50kg (110lb.) bombs on the wing racks


IMAGES (click the "loupe"):

Ha.141 3-view drawing
BV.141B 3-view drawing
BV.141 color side-views
BV.141B on the ground
Ha.141 front view
BV.141A on the ground
BV.141B viewed from top
BV.141B in flight
BV.141A on the ground
BV.141A crash-landed
BV.141B three planes lined-up
BV.141B Airfix model
NEW! Special early BV-141V.1 and V.2 DETAIL PHOTOS page.
Supplied by Mr. Lars Kambeck and Mr. Gary Webster

The BV.141 registration codes.

BV141 V1 (171) D-OTTO
Ha141 V2 (172) D-ORJE (PC+BA)
BV141 V3 (359) D-OLGE (BL+AA)
BV141 A-01 V4 (360) D-OLLE
BV141 A-02 V5 (361) BL+AB
BV141 A-03 V6 (362) BL+AC
BV141 A-04 V7 (363) BL+AD
BV141 A-05 V8 (364) BL+AE
BV141 B-01 V9 (0210001) NC+QZ
BV141 B-02 V10 (0210002) NC+RA
BV141 B-03 V11 (0210003) NC+RB
BV141 B-04 V12 (0210004) NC+RC
BV141 B-05 V13 (0210005) NC+RD
BV141 B-06 V14 (0210006) NC+RE
BV141 B-07 V15 (0210007) NC+RF
BV141 B-08 V16 (0210008) NC+RG
BV141 B-09 V17 (0210009) NC+RH
BV141 B-010 V18 (0210010) NC+RI
BV141 B-1 19 (0210011) GK+GA
BV141 B-1 20 (0210012) GK+GB
BV141 B-1 21 (0210013) GK+GC
BV141 B-1 22 (0210014) GK+GD
BV141 B-1 23 (0210015) GK+GE
BV141 B-1 24 (0210016) GK+GF
BV141 B-1 25 (0210017) GK+GG
BV141 B-1 26 (0210018) GK+GH
BV141 B-1 ?? (???) GL+AG
BV141 B-1 ?? (???) GL+AH

The above information was kindly supplied by Mr. Lars Kambeck


Mr. Gary Webster has added the URL to the website owned by Mr. Robert Lundin with many unique photos of the BV.141, take a look here
Click the image below for info on the BV.141 version with wing tip nacelle,
CLICK HERE!
