Positive Air Pressure Negative Air Pressure
Air Filtration System

Ducting Options - Positive - Negative Pressure Model (configuration)

Ducting Options for the Allerair air cleaner, air purifier models- positive and negative pressure applications.

Find a solution for every situation

Positive Pressure

This system can be used to bring outdoor air through the air cleaner and create positive air pressure in the interior space.

This pressure forces the contaminated indoor air out and replaces it with cleaned outdoor air.

The positive air configuration is used in the Air Handler central air systems and may be used to feed clean air into a heat exchanger or air duct.

Negative Pressure

The negative air configuration draws the contaminated air in through the bottom of the unit and blows it out through the top.

This system can be used to move contaminated air from indoors to outdoors through the air cleaner and create negative air pressure in the indoor space.

This pressure draws outdoor air into the interior to replace the extracted contaminated air.

The air cleaner cleans the contaminated indoor air before releasing it outdoors to avoid creating outdoor pollution and to conform with environmental regulations.

Other AllerAir air filtration systems that can be configured for Positive or Negative Pressure

• AW/AR2000 air cleaner, air scrubber, air filtration system, variable speed or dual speed, HEPA filter or Activated Charcoal / Carbon model
  air intake and clean air discharge / exhaust side can be ducted, optional flange flex hose adapters available
  ideal for hospitals, schools, construction, renovation, mold remediation, asbestos abatement, etc.
• I-6500 Series, air cleaner, air scrubber, air purifier, air filtration system, dual speed, HEPA filter, Activated Charcoal / Carbon filter
  Gel sealed on a knife edge HEPA filter system, combination HEPA filter and Activated Charcoal / Carbon filtration
