Designed for the most extreme situations and unforgiving conditions, the Jeep Rescue concept is not only the ultimate type of search and rescue vehicle - it's the ultimate execution of a Jeep off-road vehicle. That may be surprising, because it's based on the Dodge Ram chassis, complete with solid front axle and Cummins diesel engine - which means that, like the Sling Shot, it could go into production quickly if DCX so chooses.
Starting with a modern interpretation of the timeliness, classic Jeep, the Rescue hints at a future design direction for a large Jeep.
The Rescue can be configured to run almost totally open - with folding front windshield and a retractable backlite, a sliding glass sunroof in front, a fold-forward canvas roof in the rear, and removable doors (all four).
Featuring all-new body-on-frame construction with hydroformed frame rails and riding on an 80-inch wide chassis with 123-inch wheelbase and 37-inch tires, the Jeep Rescue is built for anything thrown its way. The front hydropneumatic suspension combines with the heavy-duty link-coil rear suspension to give the Rescue its solid footing on all terrain. The suspension has adjustable ride height and an additional 4-inch lift available for fording. The aforementioned 37-inch tires feature an MTR tread and run-flat capability, negating the need for a spare. On-board tire pressure control has the ability to tune tire pressures for maximum traction on all surfaces.
Powered by a Cummins diesel and featuring seating for five, the Jeep Rescue's primary mission is rescue capability, and its list of rescue and safety equipment is impressive:
* AC electric power (10 kW) generation in the field
* 3-D topographical mapping software and topographical navigation system
* Under- chassis, point-of-view cameras for avoiding danger in its path
* Passive, infrared (thermal) cameras for search and rescue
* Satellite telephone; VHF radio, digital video recorder with satellite
transmission capability
* Retractable 4-point harnesses for vehicle occupants
* Exterior perimeter lighting
* White LEV lighting for long distance visual search and reduced power use
* Folding seats in rear compartment of vehicle
* Remote control winch - front and back
