Wheelbase Driving: 18 ft 3 inches Engine: 42 ft 0 inches Engine & Tender: 87 ft 8 3/4 inches Average Weight in Working Order On Drivers: 264300 lbs Truck: 54000 lbs Trailer Front axel: 61300 lbs Rear Axel: 61200 lbs Total Engine: 440800 lbs Tender 2/3 Load: 285270 lbs
Driving Wheel Diameter: 69 inches
Cylinders Diameter: 25 inches Stroke: 34 inches
Tractive Power Main Cylinders: 64100
Grate Area: 90.3 sq ft
Boiler Diameter: 87 15/16 inches Pressure: 245 lbs
Factor of Adhesion: 4.12
Heating Surfaces Tubes & Flues: 4311 Arch Tubes & Syphons: 117 Firebox & Combustion Chamber: 344 TOTAL: 4772 Superheater: 1932
Firebox Length: 135 1/16 inches Width: 96 1/4 inches
Tubes & Flues Number: 73 202 Diameter: 2 1/4 inches 3 1/2 inches Length: 19 ft 0 inches
