Welcome to S.C.SIMEROM S.A.

Our products are used by those who work in the welded constructions and need guillotine shears and press brakes for free bending and cutting the sheets. They are also used by those who manufacture plastics and rubbers.

Our plant has been TÜV attested for welding processes since 1995.

Having over 80 years of experience in machine-tools manufacturing, a time dedicated to continous improvement in its activity, both in quality and diversity of the range of products, SIMEROM S.A. is here to offer you support in solving all of your problems related to our range of activity. You may chose items from our activity range, such as cold processing of metals, machinery and technological lines for processing plastic materials, as well as other machinery.

THE BEST CARD OF SIMEROM IS QUALITY, AVAILABILITY AND RELIABILITY. FOR SIMEROM, QUALITY HAS ALWAYS BEEN A PHILOSOPHY OF LIFE. SIMEROM IS YOUR PARTNER FOR A PROSPEROUS BUSINESS.

Cold processing of metals:

- guillotine shears, hydraulic and mechanic:

- for thickness of sheet 0,2÷13 mm (0,,078÷0,47 in);

- cutting lengths up to 3000 mm (9,84 ft);

- press brakes with a pressing force of 25 ÷100 tf;

- plate sheet expanding shears;

- eccentric mechanical presses with a pressing force of 16 ÷ 100 tf;

- profile hydraulic shears with a force up to 700 kN (70 to);

- tools and accessories for presses.

Machinery and technological lines for processing plastic materials

(thermoplastic, thermorigid, thermoelastomere)

- injection moulding machines with a volume up to 1000 cm³;

- blow forming units;

- extruders for rubber and plastic materials;

- plate extrusion lines;

- profil extrusion lines;

- tubes extrusion lines;

- thermoforming installtions for plates and foils.

Other equipments

As a producer of machine-tools, our firm has a large range of technological means of manufacturing, and also different equipments, whose technical features are listed below :

I. MANUFACTURING MECHANICAL PROCESS

1. LATHES

1.1. Longitudinal lathes. Maximum features:

> - Max. processing length between points: 5.000 mm (16.4 ft)

> - Maximum processing diameter: F1.260 mm (4.13 ft)

Note:

1. The firm has also parallel lathes numerically controlled, which allow processing of pieces with complex profile. There are also copying lathes on which you can manufacture pieces upon pattern..

> 2. For a mass production manufacture, our firm has also turret automatic lathes, with the following maximum features:

> - Maximum processing diameter: F80 mm (3.14 in)

> - Number of places in tool storehouse : 16

1.2. Vertical turning lathes. Maximum technical features:<

> - Max. diameter of piece: F 2.100 mm (6.88 ft)

> - Max. height under cross-rail: 1.500 mm (4.92 ft)

> - Max. weight on the plate: 12.000 kg

1.3. Parallel lathes with device (whirl) processing

> Our firm owns this special machine for worm processing, which makes part of the injection machines produced by our firm. The main technical features of this machine and of its manufacture process, are as follows:

> - Worm max. diameter: F120 mm (4.72 in)

> - Screw pitch, left/right: 2°/20°

> - Max. processing length between tips: 4.000 mm(13.12 ft)

1.4. Machines for manufacturing long holes

> Our firm owns this type of machine, with the following technical features:

> - Through hole processing: F75 mm (2.95 in)

> - Adjusting: F150 mm (5.9 in)

> - Boring out: F245 mm (9.64 in)

> - Max. length of hole: 4.000 mm (13.12 ft)

> - Max. diameter: F620 mm (24.4 in)

2. DRILLING - TAPPING

2.1. The firm has a range of drilling machines, such as:

> - Table drilling machines

> - Column drilling machines

- Standard drilling machines

> - Radial drilling machines

> Max. technical features of radial drilling machines are as follows:

> - Maximum diameter of full drilling: F 80 mm (3.14 in), piece

material : OL 60

- Max. thread that can be processed: 3" ÷ M75

> - Minimum and maximum diameter of holes circle: 1.560÷5.580 mm

( 5.11¸18.3 ft).

2.2. Machines for inside vertical threads. Main technical features:

> - Max. diameter of the inside thread on OL 60: M16

> - Max. length of thread: 63 mm (2.48 in)

2.3.

some of them are clasic, others are numerically controlled, with a

positioning precision of ± 0.008 mm and swinging tables. Their

max. technical features are:

> - Useful table surface : 900 x 1.400 mm (35.4in x 4.59ft)

> - Longitudinal shifting the table: 1.120 mm (3.67 ft)

> - Side motion of table: 710 mm (27.95 in)

3. PLANING

> Max. technical features of planing machines are:

> - Planing length: 6.000 mm (19.68 ft)

> - Planing width: 1.600 mm ( 5.24 ft)

> - Planing height: 1.250 mm ( 4.1 ft)

4. SLOTTING

> Max. features:

> - Max. slotting length

> - Max. longitudinal motion of the table: 630 mm (24.8 in)

> - Max. lateral motion of table: 560 mm (22.04 in)

5. MILLING

5.1. Regarding the milling method,, the firm has universal milling

machines, horizontal and vertical milling machines, but also

longitudinal portal milling machines.

> The maximum features for longitudinal double column milling machines, are as follows:

> - Maximum gauge dimensions: 7.136 x 1.270 mm x mm (23.41 x

4.16 ft x ft)

> - Max. motion of table: 6.460 mm (21.19 ft)

> - Max. stroke of table: 1.400 mm (4.59 ft)

5.2. For some certain copying workks, for pieces with a complex space

profile or punching, molding works, we use milling machines

numerically controlled or copying machines, with means of

reading the quote and numberr of passings.

> Max. features of copying machines, are:

> - Max. weight of piece: 3.500 kg (7,716 Lbs)

> - Turning tables support surface: F600 mm (23.62 in)

6. PROCESSING THE GEAR WHEELS

6.1. Milling machines for gears, using the rolling method

> Max. technical features:

> - Max. modulus of gears: 12 mm (0.47 in)

> - Max. diameter of milled notching wheels: F1.250 mm (4.10 ft)

> - Max. width of gears: 350 mm (13.77 in)

6.2. Gear shaper, using the rolling method

> Max. technical features:

> - Min. and max. diameter of wheel for the

outward toothing: F10 ÷ F250 mm (0.39÷9.84 in) - Min. and max. diameter of wheel for the inward toothing: F30 ÷ F250 mm (1.18÷9.84 in)

> - Max. module: 4 mm (0.15 in)

6.3. Planing machines for gears, using the rolling method

> Max. technical features:

> - Max. diameter of wheels: F500 mm (19.68 in)

> - External max. module: 10 mm ( 0.39 in)

> - Max. width of gear rim: 80 mm ( 3.14 in)

6.4. In order to grind the gears, our firm has gear grinders which use

the NILES proceeding, with the following main technical features:

> - Min. inward diameter of gears: F50 mm ( 1.96 in)

> - Max. outward diameter of gears: F500 mm (19.68 in)

> - Maximum tilting angle of teeth: 45°

> - Normal minimum module: 2 mm (0.07 in)

> - Normal maximum module: 10 mm (0.39 in)

> - Min./max. number of teeth: 12 ÷ 140 (cogs)

> Features for MAAG proceeding:

> - Min. inward diameter/max. outward diameter of

wheel: p; F20÷300mm (0.78÷11.81 in)

> - Min/max number of teeth: 10/120

> - Min/max module: 1.5/10

7. BORING - MILLING

> Max technical features of boring and milling machines are as follows:

> - Max shifting of slide on machine bed: 9.800 mm (32.15 ft)

> - Max shifting on vertical (axle Y): 1.900 mm ( 6.23 ft)

> - Diameter of arbor which has to be bored: F150 mm ( 5.9 in)

NOTE : The firm owns boring and milling machines of small and medium size, produced in Germany, Switzerland and Chech Republic, with a special processing precision and supplied with optical read out for quote, or numerically controled. The equipment of these machines allows a space processing (simultaneous order of 3 or 4 axles).

8. GRINDING

The firm has grinding machines of different types, and you have their max. technical features listed below.

8.1. Plane grinding machines for guides

> - Grinding length: 5.000 mm (16.4 ft)

> - Grinding width: 1.250 mm ( 4.1 ft)

> - Max. height to be ground: 1.000 mm ( 3.28 ft)

8.2. Inward rectifying machines

> - Max diameter to be ground: F400 mm (15.74 in)

> - Min diameter: F30 mm ( 1.18 in)

> - Max length to be ground: 300 mm (11.81 in)

8.3. Outward grinding machines

> - Max length to be ground: 4.000 mm (13.12 ft)

> - Max diameter to be ground: F630 mm (24.8 in)

8.4. Threads grinding machines

> - Max diameter to be ground: F254 mm (10 in)

> - Min diameter to be ground: F19 mm (0.74in)

> - Max thread pitch: 48 mm (1.88 in)

8.5. Machines for grinding rectangular cotter channel

> - Max diameter to be ground: > F 125 mm (4.92 in)

> - Min diameter to be ground: F 25 mm (0.98 in)

> - Max length of part: 1.400 mm (4.59 ft)

8.6. Machines for grinding profiles (numerically controled)

> - Max length of part: 250 mm (9.84 in)

> - Numerically controled equipment.

9. HONING

The main technical features of these machines are:

> - Min diameter for honing: F20 mm ( 0.78 in)

> - Max diameter for honing: F130 mm ( 5.11 in)

> - Min length for honing: 50 mm ( 1.96 in)

> - Max working length: 380 mm (14.96 in)

10. LEVELLING VIBRATOR

For outward surfaces where is needeD a surface rugosity of 0.2 m. The firm may provide this type ofdevice with the following technical features:

> - Max diameter of piece: F 400 mm (15.74 in)

> - Max length of piece: 2.000 mm ( 6.56 ft)

II. HEAT TREATMENTS

1. FORGE - features:

> - Forging hammer: 250 kgf

> - Maximum mass: 6 kg (13.22 Lbs)

> - Minimum mass: 0.5 kg (1.10 Lbs)

> - Maximum section for starting: 70 mm²

2. HEAT TREATMENT

2.1. Hardening-tempering

> Maximum dimensions:

> - Max diameter: F1.000 mm (3.28 ft)

> - Max length: 4.000 mm (13.12ft)

2.2. Ionitriding

> Maximum dimensions:

> - Max diameter: F650 mm (25.59 in)

> - Max length: 4.000 mm (13.12 in)

2.3. Hardening through high frequency (current high frequency)

> Maximum dimensions of turning part :

> - Max diameter: F1.000 mm ( 3.28 ft)

> - Max length: 4.000 mm (13.12 in)

3. WELDING

- Manual electrical welding for parts , weighting less then 8 tones.

> - Welding with protecting gas: Ar +CO₂

> - Automatic welding, straight, under flux layer

> - Argon welding for non-ferrous metals, stainless steel and refractory steel

> - Installation for a head to head welding of bands 1.5x1.5 mm (0.05 x 0.05 in)

3.1. Heat stress relief

> It is made in an oven with the following maximum dimensions:

- 4.700 x 2.500 x 2.300 mm (15.41 x 8.2 x 7.54 ft)

3.2. Vibrating stress relief

It is made through a device, where the minimum weight of parts to be trated, is of 50 kg (110.23 Lbs).

3.3. Sand blasting

> Is made in equipment of the following dimensions:

> - 4.800 x 2.900 x 3.000 mm (15.74 x 9.51 x 9.84 ft)

> - Maximum allowed weight for parts: 8 tons

III. METALIC COVERING

1. BROWNING

> - Charge gauge for covering: 1.600x500x250 mm (5.24ft x 19.68in x 9.84in)

> - Max weight: 120 kg (264.55 Lbs)

2. ZINCIFYING IN CYANIDE BATH

> - Max dimensions of charge: 1.200x300x300 mm (3.93ftx11.81in x 11.81in)

3. HARD CHROMING

> - Max dimensions of charge: 1.800 x 220 x 220 mm (5.9ft x 8.66in x 8.66in)

IV. HEAT CUTTING

> Heat cutting with oxygen can be:

> - free cutting

> - following a mechanic pattern

> - following a pattern with optical read out,to which:

> - min/max size of drawing is 800 x 250 mm (31.49 x 9.84 in)

> - max size of plate sheet is 7.600 x 2.850 mm (24.93 x 9.35 ft)

> - reducing ratio: 1/5; 1/10

> Technical endowment and skilled operators are enabling SIMEROM to offer itself in order to manufacture units or assemblies wich make part of your products, by processing, complexe heat treatment, partnership, consulting.

> SIMEROM cooperation with firms which gained a worldwide fame has been led on two main trends:

> - To purchase some imported parts, which have increased our products quality and reliability: Vickers, Schneider Electric (Telemecanique), ELGO Electric.

> - To reach to parteners who will be able to advertise and sell our products. Volz, C & A Carter and Techna are already our dealers on European Market.

> At last , we would appreciate if you could help as to reach to different firms interested in our products range and send their addresses.

> Should our offer meets your requirements, do not hesitate to contact us to the adress below:

Looking forward to receiving the best answer, we remain sincerely yours,

> General Manager,

> jr. Constantin Dichel

Company Profile

SIMEROM S.A. celebrates in the year 2000, 79 years since it was established as a factory, under the name on " BENKER & JIKELY ". It then comprised one workshop for processing metals, where a wide range of equipment and spare parts for the textile industry was machined.

Under the name of " MECANICA ", in the early 60s, the company specializes in design and manufacture of machine-tools for processing metals using cold distorsion, to produce in the 70s the first machine-tools for processing plastic materials.

KEY PERSONNEL AT S.C.SIMEROM S.A.

Managing Director - jr.Constantin Dichel

Phone:0040-69-433102 Fax:0040-69-211170 Email:[email protected]

Executive Director - eng.Ioan Cotoara

Phone:0040-69-431467 Fax:0040-69-211170 Email:[email protected]

Commecial Director - eng.Ionita Medesan

Phone:0040-69-431601 Fax:0040-69-211170 Email:[email protected]

Financial Director - ec.Georgeta Danciu

Phone:0040-69-431481 Fax:0040-69-211170 Email:[email protected]

Contact Information

Marketing - eng.Sebastian Burlac Phone:0040-69-210418 or 0040-69-431102 or 0040-69-430620 int. 229 Fax:0040-69-211170 Email:[email protected]

Export - tehn.Precup Rau Phone:0040-69-431481 or 0040-69-430620 int. 120 Fax:0040-69-211170 Email:[email protected]

Sales - eng.Marian Calciu Phone:0040-69-431659 or 0040-69-430620 int. 152 or 182 Fax:0040-69-211170 Email:[email protected]

Spare parts - eng.Ileana Rodean Phone:0040-69-431659 or 0040-69-430620 int. 152 or 182 Fax:0040-69-211170 Email:[email protected]

Telephone: 0040-69-431102
FAX: 0040-69-211170
Postal address: ROMANIA, SIBIU, STR.LECTOR,NR.3
Electronic mail: General Information: [email protected]
Sales:
Customer Support:
Webmaster: [email protected]

This page created by : dipl.eng.Sebastian Burlac, using the: Front Page 2000

Send mail to [email protected] with questions or comments about this web site.
Last modified: April 24, 2001

Hosted by www.Geocities.ws

Company Profile

Contact Information

Send mail to [email protected] with questions or comments about this web site. Last modified: April 24, 2001

Send mail to [email protected] with questions or comments about this web site.
Last modified: April 24, 2001
