TASCAM M-520 PROFESSIONAL MIXING CONSOLE - FEATURES: TASCAM PS-520 POWER SUPPLY UNIT. A MINIMUM OF 716 KNOBS, SWITCHES & FAD-ERS CONTROL THE TASCAM M-520 MIXING CONSOLE! 34 FADERS TOTAL, 20 DIRECT OUTPUTS, 20 SEND & RECIEVE CONNECTIONS PER CH. FOR COM-PRESSOR, NOISE GATE ETC.. EACH CHANNEL STRIP = PHANTOM POWER MIC, ATTENUATION 30-0, PHASE REV. NORM. SWI-TCHS TAPE INPUT & OUTPUTS, LINE, TRIM WITH OVER LOAD PILOTS, PRE FADER & POST FADER TAPE SWIT-CHES, AUX 1&2 CONTROLS, PRE & POST TAPE SWITCHES, AUX 3&4 CON-TROLS, PILOT LIGHTS FOR AUX FUNCTIONS, AUX MUTE SWITCHES, PARA-METRIC EQ = ON/OFF 6 EQ CON-TROLS, FREQUENCY SWEEP OF 2.5K, 6.5K, 15K + LEVEL CONTROL, FREQ. SWEEP 100HZ, 350HZ, 500KHZ + LEVEL, FREQ. SWEEP 50HZ, 350HZ, 500HZ + LEVEL EQ CONTROLS. 8 CH. ASSIGN SWITCHES, SOLO, PFL SWITCH, PAN & CH.FADER. 12 GIANT VU METERS WITH PEAK LEDS PER METER. METER SLECT SWITCHES. BUSS = 8 EXL BUSS OUTPUTS, 8 SUB BUSS INPUTS, 8 CH. FADERS FOR BUSSES, LEVEL CONTROL & PAN CONTROL FOR EACH BUSS CH. BUSS & TAPE SWITCHES FOR EACH BUSS CH. AUX = 4 MASTER FADERS, & 4 STEREO AUX SEND & RETURN PER CH. 20 TAPE SUB MASTER OUTPUTS, 20 AUX SUB MASTER OUTPUTS/INPUTS. SOLO LEVEL MAS-TER CONTROL, STEREO MAS-TER A & STEREO MASTER B FADERS. FOUR GIANT AUX METERS WITH PEAK LEVEL INDICATORS. XLR, RCA & '1/4 CONN-ECTIONS. 2 PHONO INPUTS & 4 INST. INPUTS. TALK BACK SWITCH, HEAD-PHONE CONTROL, SLATE, AN ASSORMENT OF TESTTONE SWITCHES & CON-TROLS. THE TASCAM M-520 IS A PROFESSIONAL VINTAGE CONSOLE WITH WARM ANALOG SOUND & BROAD BANDWIDTH SUPPORTED BY TASCAM'S FAMOUS TRADITIONAL HEADROOM AND PERFORMANCE. THIS CONSOLE IS VINTAGE +4 & SOLID +3 EXTENDED METERING SOUND AND PERFORMANCE. HERE AT SAMPLIFIED MASTERING STUDIOS, WE STILL USE THE TASCAM M-520 BECAUSE IT PRODUCES THE BEST IN TRADITONAL ANALOG TONE. THE TASCAM M-520 IS PART OF OUR MIXING CONSOLE CASCADE CHAIN LINK.
ALESIS STUDIO SERIES 1622 MONOLITHIC INTERGRATED SURFACE AUDIO MIXING CONSOLE - THERE ARE AT LEAST 268 KNOBS, SWITCHES AND FADERS TO CONTROL THE ALESIS 1622. EACH CHANNEL STRIP = TRIM, 10 MHZ EQ, 100 MHZ EQ, AUX PRE - SEND 1 & 2 , AUX POST SEND 3456. MASTER SWITCH CONTROL, SUB MASTER SWITCH CONTROL, MUTE, SOLO, PAN, CHANNEL FADER. MASTER CONTROL PANEL = SEND MASTER & AND PRE 1 & 2 POST 3456. RETURNS 1234 WITH AUX PANING FOR 1234. AUX STEREO RETURNS 5678. SUB MASTER TO MASTER ASSIGN SWITCHES, SUB MASTER CHANNEL 1 & 2 FADERS, SUB MIX PAN 1 & 2, MASTER OUTPUT CHANNEL 1 & CHANNEL 2 FADERS. TAPE MONITOR MASTER SWITCH, CONTROL ROOM DEFEAT SWITCH, AND GIANT VOLUME MONITOR DIAL. 16 MICROPHONE XLR INPUTS, 16 DIRECT OUTPUTS, -10 +4 SELECTOR, ALL CONNECTIONS ARE 1/4 INCH & XLR COMPLETE. CONTINUED ON NEXT PAGE
