 Step 1
- Download
Download FFmpeg here (
static /
shared )
and MP4Box
here
then extract them with
WinRAR
or
7-Zip to C:\Windows
If you wish, you could
Build your own FFmpeg!
Step 2 - Prepare
Copy / Capture / Rip your videos into
your hard disk. You can use one of these to rip
your DVDs:
AnyDVD (shareware)
DVDFab Decrypter (free edition)
Step 3 - Upgrade
Upgrade your iPod
software.
Download the lastest software
here.
Step
4 - Video format
Choose your iPod video
format:
MPEG-4 ASP/H.263 or
MPEG-4 AVC/H.264
► MPEG-4 ASP/H.263
___*)
Blue means editable
|
Widescreen 16:9 at
FILM (23.976 fps) |
| |
ffmpeg -y
-i vts_01_1.vob -r
24000/1001
-g
240 -keyint_min 24 -vcodec mpeg4
-s 624x352 -b
1800kb -bt 1800kb -maxrate 2500kb -bufsize
800kb -mbd 2 -flags +4mv+trell -aic 2 -cmp 2 -subcmp
2 -acodec aac -ac 2
-ab
160kb -vol
512
-title "Box
Office" -pass
1 myipod.mp4 |
+ PAL (25 fps) = -r 25 -g 250
-keyint_min 25
+ NTSC (29.97 fps) =
-r 30000/1001 -g 300
-keyint_min 30
+ Deinterlace = -deinterlace
+ 2-pass mode = do reencode and change
-pass 1
to -pass 2
+ Quality mode = change
-b 1800kb -bt 1800kb
to -qscale 4
(range 0 ~ 31) |
► MPEG-4 AVC/H.264
___*)
Blue means editable
|
Widescreen 16:9 at
FILM (23.976 fps) ~ Profile: Baseline,
Level: 1.3 |
| |
ffmpeg -y
-i vts_01_1.vob -r
24000/1001 -g 240 -keyint_min 24 -vcodec h264 -level 13
-s 320x176 -b
700kb
-bt 700kb -maxrate 768kb -bufsize 244kb -qcomp 0.60 -cmp 1 -chroma 1
-me_range 16 -sc_threshold 40 -me umh
-subq 6 -qmin 2 -qmax 51 -qdiff 4 -i_qfactor
0.71428572 -rc_eq blurCplx^(1-qComp) -chromaoffset 0 -loop 1 -parti4x4 1 -partp8x8 1
-partp4x4 1 -acodec
aac -ac 2 -ab
128kb -vol
512
-title "Box
Office" -pass
1
myipod.mp4 |
|
Widescreen 16:9 at
FILM (23.976 fps) ~ Profile: Baseline,
Level: 3 |
| |
ffmpeg -y
-i vts_01_1.vob -r
24000/1001
-g
240 -keyint_min 24 -vcodec h264 -level 30
-s 624x352 -b
1400kb
-bt 1400kb -maxrate 1500kb
-bufsize 480kb -qcomp 0.60 -cmp 1 -chroma 1
-me_range 16 -sc_threshold 40 -me umh
-subq 6 -qmin 10 -qmax 51 -qdiff 4 -i_qfactor
0.71428572 -rc_eq blurCplx^(1-qComp) -chromaoffset 0 -loop 1 -parti4x4 1 -partp8x8 1
-partp4x4 1 -acodec
aac -ac 2 -ab
160kb -vol
512
-title "Box
Office" -pass
1
myipod.mp4 |
+ PAL (25 fps) = -r 25 -g 250
-keyint_min 25
+ NTSC (29.97 fps) =
-r 30000/1001 -g 300
-keyint_min 30
+ Deinterlace = -deinterlace
+ 2-pass mode = do reencode but change
-pass 1
to -pass 2 |
Step 5 - Make it
compatible
Step 6 - Transfer
You need
iTunes to get
your videos onto your iPod.
Drag your videos into
your iTunes library in the folder or playlist of
your choosing then attach your iPod to your
computer and synch the iPod with iTunes.
Step 7 - Small note
Make sure your iPod's TV-out switched
off
|
