MAXIMA
Basic Wiring Diagrams
MAXIMA 1999
WIRE COLORS LOCATION
12 VOLTS CONSTANT WHITE/RED or WHITE/VIOLET IGNITION SWITCH HARNESS
IGNITION 1 BLACK/WHITE or BLACK/RED IGNITION SWITCH HARNESS
ACCESSORY/HEATER BLOWER 1 BLUE or WHITE/BLACK IGNITION SWITCH HARNESS
STARTER BLACK/YELLOW or BLACK/WHITE IGNITION SWITCH HARNESS
STARTER 2  RED/YELLOW or RED IGNITION SWITCH HARNESS
PARKING LIGHTS RED/GREEN (+) STEERING COLUMN HARNESS
DOME LIGHT RED/WHITE (-) DR KICK PANEL
POWER DOOR LOCK LIGHT. GREEN/RED (-) DR DOOR
POWER DOOR UNLOCK GREEN/YELLOW (-)  (TYPE B)
TRUNK RELEASE VIOLET/YELLOW (-) DR KICK PANEL
TACH SENSOR WHITE/GREEN AT ECM FRONT OF CONSOLE
BRAKE RED/GREEN (+) SWITCH ABOVE BRAKE
HORN GREEN/WHITE (-) STEERING COLUMN
FACTORY DISARM GREEN/YELLOW (-) N/A
MAXIMA  1996-1998
WIRE COLORS LOCATION
12 VOLTS CONSTANT WHITE/VIOLET IGNITION SWITCH HARNESS
IGNITION 1 BLACK/RED IGNITION SWITCH HARNESS
IGNITION 2 RED/YELLOW IGNITION SWITCH HARNESS
ACCESSORY/HEATER BLOWER 1 WHITE/BLUE IGNITION SWITCH HARNESS
STARTER BLACK/WHITE IGNITION SWITCH HARNESS
STARTER 2 RED/BLUE IGNITION SWITCH HARNESS
PARKING LIGHTS ( + ) RED/GREEN AT HEADLIGHT SWITCH
DOME LIGHT RED/WHITE AT THE BODY CONTROL MODULE
POWER DOOR LOCK LIGHT GREEN/RED DRIVER KICK PANEL
POWER DOOR UNLOCK GREEN/YELLOW DRIVER KICK PANEL
TACH SENSOR WHITE/GREEN AT ENGINE CONTROL MODULE

BRAKE

 RED/GREEN AT SWITCH ABOVE BRAKE PEDAL
HORN GREEN/WHITE STEERING COLUMN
ALARM DISARM GREEN/YELLOW IN DRIVER DOOR
MAXIMA     1995
WIRE COLORS LOCATION
12 VOLTS CONSTANT WHITE/VIOLET IGNITION SWITCH HARNESS
IGNITION 1 BLACK/RED IGNITION SWITCH HARNESS
IGNITION 2 RED/YELLOW IGNITION SWITCH HARNESS
ACCESSORY/HEATER BLOWER 1 WHITE/BLUE IGNITION SWITCH HARNESS
STARTER BLACK/HITE IGNITION SWITCH HARNESS
PARKING LIGHTS ( + ) RED/GREEN AT HEAD LIGHT SWITCH
DOME LIGHT RED/WHITE (-) JCT BOX BEHIND CONSOLE
DOOR TRIGGER
POWER DOOR LOCK LIGHT GREEN/RED AT LOCAL CON UNIT
POWER DOOR UNLOCK GREEN/YELLOW AT LOCAL CON UNIT TYPE (B)
TACH SENSOR WHITE/GREEN AT ENGINE CONTROL MODULE

BRAKE

 RED/GREEN AT SWITCH ABOVE BRAKE PEDAL
HORN GREEN/WHITE STEERING COLUMN
ALARM DISARM GREEN/YELLOW DRIVER KICK PANEL
