Traffic Analysis for FR/0 : Net 1 : IBM 2210 Frame Relay Interface : V.35 DTE

System:ATM in
Maintainer:
Interface:FR/0 : Net 1 : IBM 2210 Frame Relay Interface : V.35 DTE (2)
IP:192.168.1.1)
Max Speed: 7000.0 Bytes/s (frame-relay)

The statistics were last updated Friday, 29 December 2000 at 16:21,
at which time 'ATM' had been up for 140 days, 23:31:56.
`Daily' Graph (5 Minute Average)
day
Max  In: 30.0 kb/s (53.6%) Average  In: 6240.0 b/s (11.1%) Current  In: 11.6 kb/s (20.7%)
Max  Out: 12.1 kb/s (21.6%) Average  Out: 4256.0 b/s (7.6%) Current  Out: 6736.0 b/s (12.0%)
`Weekly' Graph (30 Minute Average)
week
Max  In: 30.0 kb/s (53.6%) Average  In: 5240.0 b/s (9.4%) Current  In: 3288.0 b/s (5.9%)
Max  Out: 21.3 kb/s (38.1%) Average  Out: 3784.0 b/s (6.8%) Current  Out: 1792.0 b/s (3.2%)
`Monthly' Graph (2 Hour Average)
month
Max  In: 43.0 kb/s (76.7%) Average  In: 4992.0 b/s (8.9%) Current  In: 6408.0 b/s (11.4%)
Max  Out: 24.9 kb/s (44.4%) Average  Out: 3640.0 b/s (6.5%) Current  Out: 2768.0 b/s (4.9%)
`Yearly' Graph (1 Day Average)
year
Max  In: 54.5 kb/s (97.3%) Average  In: 4392.0 b/s (7.8%) Current  In: 4504.0 b/s (8.0%)
Max  Out: 38.6 kb/s (68.9%) Average  Out: 3320.0 b/s (5.9%) Current  Out: 2792.0 b/s (5.0%)

GREEN ### Incoming Traffic in Bits per Second
BLUE ### Outgoing Traffic in Bits per Second
DARK GREEN### Maximal 5 Minute Incoming Traffic
MAGENTA### Maximal 5 Minute Outgoing Traffic
