Are you sick of tooth approximations that just do not fit in your model. Here is my answer. The involute profile is approximated by a spline with 10 points minimum.
The Real Involute Gear ProfileRight mouse pick - save as
Involute Gear, Use as a template, not an iPart. 12 tooth to 400 tooth. Diametral pitch -- 1/2 to 36, pressure angle 14 1/2, 20 and 25 degrees. Yes, there is a extra spread sheet for doing the bores and keyways. Download the file, -- 480k R5.3
Internal Involute Gear, As above but. 24 tooth to 400 tooth. Diametral pitch -- 1/2 to 36, pressure angle 14 1/2, 20 and 25 degreesDownload the file, file 101k
Do you need more power transmission parts? Electric Motors? etc.
Charles Bliss Power Transmission Web Page.		Link to Charles Bliss Power Transmission Web Page
