Ural-5323 (s. 1991) is heavy-duty off-road truck, designed special for army service. It has units hermetization system and remote tyre pressure control. Payload: 26,456 lbs. Drive: 8x8. Framework. Suspension: dependent, solid axles with leaf springs, rear - solid axles on balance-cart.rear - solid axles on balance-cart. Engine: YaMZ-238B type - V8 turbo-diesel, ohv, displacement 14,866 cc (bore 5.12", stroke 5.51"). It puts out 300 hp @ 2,000 rpm. Torque 885 ft.-lb. @ 1,200...1,400 rpm. Gearbox: 8x2 speed, locking transaxle differential. Top speed: 53 mph. Wheel base: 9'0.3"+4'7.1". Cargo platform size: 18'7.8"x7'7.7"x.3'3.4". Maneuverability: turning circle 85.3', max. ascent angle 31 deg., hillside: 20 deg., ground clearance 15.7", overcome ford: 3'11", overcome trench 3'11". Brakes: drums, with air-hydraulic control. Full weight: 47,245 lbs, max. towing weight: 35,274 lbs. Fuel tanks: 79.3 + 55.5 gal. Range: 650 miles. Tyres: 14.00-20 146G. Pressure: controlled.
There are several models on 5323 index:
Ural-5323-20 and Ural-5323-21 have KamAZ cab.
|
|
Ural-5323-22 has IVECO cab.
Ural-53236 - a modification of 5323-22 model. Payload: 22,046 lbs.
Ural-5324-20 - a modification of 5323-20 model. Payload: 22,046 lbs.
Ural-5423-10 model - a tractor. Variant of 5323 model. Full weight: 46,297 lbs, max. towing weight: 85,760 lbs.
