Country of Origin ; italy
Wing Span 11.22m (36'11 ft)
Length 11.24m (36'10 ft)
Height 3.99m (13'2 ft)
Weight, empty 4,930kg (10,870lb)
Weight, max 6,350kg (14,000lb)
Engine 1,995 kgp (4,400 lb st) Rolls Royce Viper 680-43
Maximum speed (Clean): 435 knot (806 km/h) / 960km/h (600mph)
Cruising speed
Initial Climb 4,500 ft/min (1,370 m/min)
max climb 8000ft/min (2438m/min)
Range 816 nm (1,512 km) / 1170km (730 miles)
Service Ceiling 44,000 ft (13,400 m) / 49,200ft (15,000m)
Crew Two seat trainer and light attack aircraft 326K is a single seater
Task: Advanced trainer, lead-in fighter trainer / light attack
First Flight: August 2nd 1976
Crew: 2
Wing Span: 10,86 m incl. tip-tanks (MB-339A)
11,22 m incl. tip-tanks (MB-339C)
Wing Area: 19,3 m�
Length: - 10,97 m (MB-339A)
- 11,24 m (MB-339C)
Height: 3,99 m
Engine (s): - MB-339A: Rolls-Royce Viper Mk632-43 turbojet, 17,9 kN thrust (1x)
- MB-339C: Rolls-Royce Viper Mk680-43 turbojet, 19,6 kN thrust (1x)
Weight: - 3125 kg (MB-339A)
- 3310 kg (MB-339C)
Max.Take off weight: - 5895 kg (MB-339A)
- 6350 kg (MB-339C)
Max. Speed: - 898 km/h (MB-339A at sea level)
- 902 km/h (MB-339C at sea level)
Max. Range: - 2110 km (ferry range with drop-tanks MB-339A)
- 2035 km (ferry range with drop-tanks MB-339C)
- 393 km (Combat radius MB-339A)
- 500 km (Combat radius MB-339C)
Weapons: - MB-339A:
