• Displacement: 4,100 tons (full load)
• Length: 412 ft
• Beam: 47 ft
• Draught: 19 ft
• Speed: 29 kts
• Range: 4,000 miles at 18 kts
• Compliment: 253

• Sea Dart twin launcher; radar/semi active radar guidance to 21.5 nm at Mach 2; 22 missiles; limited anti ship capability

• 1 4.5 in (114 mm)/55 Mk 8; 25 rds/min to 11.9 nm anti-surface; 6 km (3.3 nm) anti-aircraft.
• 2 or 4 20 mm GAM-BO1; 1,000 rds/min to 2 km
• 2 20 mm Mk 7A; 800 rds/min to 2 km
• 2 20 mm Vulcan Phalanx Mk 15; 6 barrels per launcher; 3,000 rds/min combined to 1.5 km

ESM/ECM

• UAA 2 intercept
• Type 670 and Type 675 jammers

• 6 324 mm STWS Mk 3 (2 triple) tubes

• Decoys
• Outfit DLB.
• 4 Sea Gnat 6-barrelled
  130 mm/102 mm 6-barrelled launcher
• Type 182; towed torpedo decoy

• Air Search
• Type 1022; D-Band; range 145 nm
• Surface Search
• Type 966E/F-band
• Navigation
• Type 1006 or Type 1006; I-Band
• Fire Control
• 2 Type 909 or 909(1) (R 06); I/J-Band

• Type 2050 or Type 2016; Hull Mounted; active search and attack
• Type 162M; hull mounted; bottom classification; 50kHz

• 1 Lynx HMA 3/8
