Maintenance: tyres

The legal minimum depth of the cutting is 1 mm (0.03937") in Belgium, but it is much safer to replace your tyres sooner.
The fronttyre and the reartyre have the same dimensions: 2.00/17.
The tension at front should be 1.8 kg/cm� (25.60 psi).
At the rear: 2.0 kg/cm� (28.45 psi).
When replacing the tyres, be sure that the ribbon that covers the nuts of the spokes is in the right place and is not damaged.


Front wheel

NrDescription and ordernumber
1wheel assy (44600-099-000)
2hub and panel assy (44620-093-000)
3hub assy (44610-093-000)
4panel and brake assy (45050-093-001)
5axle (44301-093-003)
6cone race (44302-093-003)
7case ball (44303-093-003)
8hub (44601-093-003)
9hex. nut M11 (90313-093-003)
10hex. nut M11 (90314-093-003)
11washer (90505-093-003)
122x11 balls (96211-07000)
NrDescription and ordernumber
13panel (45100-093-013)
14brake shoe (45120-093-003)
15spring (45133-093-003)
16hex. nut M11 (90312-099-003)
17hex. nut M11 (94001-11000)
18washer (94101-11000)
19collar (44311-093-000)
20gear box speedo (44800-099-003)
21spoke (36) (97463-11214)
22rim 17" (42701-122-690)
23tire (44711-099-158)
24tube (44712-099-158)
25flap (44713-099-158)


Rear wheel

NrDescription and ordernumber
1wheel assy (42600-099-000)
2hub and panel assy (42620-099-000)
3hub assy (42610-099-003)
4panel assy (43050-099-013)
5hub (42601-099-003)
6axle (42301-099-003)
7cone race (42602-099-003)
8case ball (42603-099-003)
9collar (42315-099-003)
10hex. nut M12 (90313-099-003)
11hex. nut M12 (90315-099-003)
NrDescription and ordernumber
12washer (90505-099-003)
132x13 balls (96211-06000)
14panel (43100-099-013)
15brake shoe (45120-093-003)
16spring (45133-093-003)
17washer (94101-12000)
18rim 17" (42701-122-690)
19tire (44711-099-158)
20tube (44712-099-158)
21flap (44713-099-158)
22spoke (36) (97524-21220)
