Minnesota ARMER System Tower ID's & Frequencies
System ID: 40F / BEE07 (decimal 1039 / Motorola 781831)
Note on Rebanding: Starting April 2008 many of
the frequencies used by the ARMER system have changed. This is a result of
a long planned resolution with Nextel to address interference
issues. This process is known as "rebanding". There
have been no reports of any problems with compatible scanners and the new
frequencies. In most cases, the change is simply to subtract
15mhz from any frequency greater then 861.000mhz. For example,
867.3875 becomes 852.3875 under the new plan. Hopefully these
changes will improve reception for users in areas that have heavy Nextel
repeater coverage.
"How do I use this information?" - These are the digital control channel and voice frequencies for the statewide digital trunked radio system. If you haven't already, read the How Does it All Work FAQ page. If you have a compatible digital scanner, enter the primary and alternate control channels into a new bank. You do not need to enter the voice frequencies unless the data channels are not listed. Follow the links on the Home Page for the talkgroups for each individual agency.
Every Tower and system has a primary control channel that is used the majority of the time for transmitting trunking control data. Every tower also has 2 or 3 alternate/backup data control channels that can be used if the primary data channel goes offline. Voice traffic is carried on the remaining channels. The alternate control channels can be used for voice traffic if the other channels are busy.
Short list of Towers currently on line
101 - MN Metro
102 - Anoka Co
103 - Dakota Co
104 - Carver Co
105 - Hastings & eastern Dakota Co
106 - Isanti Co - Cambridge
107 - Washington Co
109 - Minneapolis
121 - ?
122 - ?
123 - ?
124 - Morrison Co - Little Falls
125 - Goodhue/Rice County (areas between Dakota & Olmsted)
201 - Hennepin Co East
202 - Hennepin Co West
203 - Ramsey Co & St Paul
213 - Stearns Co - Kimball region (south)
214 - ? Possible Henn Co Sheriff mobile system
215 - Stearns Co - Farming region
216 - Stearns Co - Avon region
217 - Stearns Co - Grove Township region
218 - Stearns Co - Belgrade region
219 - Stearns Co - St Cloud City
220 - Olmsted Co & Rochester
405 - Benton Co - Gilman Tower
Tower 101 / 257 - MN Metro (WPER943)
NAC 401 - Provides primary
coverage in Mpls-St Paul metro area for State Agencies, Transit, EMS, and other
users. map Not
rebanded (not necessary)
Primary |
Alternate |
Alternate |
Alternate |
860.2375 |
858.2375 |
858.2625 |
859.7625 |
Voice channels: 856.2375, 856.2625, 856.7625, 856.9375, 857.2375, 857.2625, 857.7625, 857.9375, 858.4375, 858.7375, 858.7625, 858.9375, 859.2375, 859.2625, 859.4375, 859.7375, 859.9375, 860.2625, 860.4375, 860.9375, 860.9875
Tower 102 / 258 - Anoka County (WPKG278) NAC
402 - Primary system
for Anoka County regional users. Map
Rebanded as of 4/25/08
Primary |
Alternate |
Alternate |
Alternate |
853.3875 |
866.9375 |
852.8875 |
852.3875 |
Voice channels: 851.1375, 851.3125, 851.3875, 851.6875, 852.0625, 852.2125, 852.8125, 853.0875, 853.6875, 853.9125
Tower 103 / 259 - Dakota County (WQGY396) - Primary system for
Dakota County regional users. Map
Rebanded as of July 08
Primary |
Alternate |
Alternate |
Alternate |
853.5625 |
851.1625 |
853.0625 |
853.3125 |
Voice channels: 850.4875, 851.8375, 852.1875, 852.5875, 852.9875, 853.3375, 853.5875
Tower 104 / 260 - Carver County (WPKG241) - Primary system for Carver County
regional users. Map
Rebanded as of 4/08 (Alternate CC &
Voice freqs unconfirmed)
Primary |
Alternate |
Alternate |
Alternate |
852.4375 |
851.8875 |
852.075 |
853.7875 |
Voice channels: 851.4375, 852.700, 852.9375, 853.225, 853.4625
Tower 105 / 261 - Hastings & Dakota East (WPKG276) - Backbone system for
stage agencies in southeast metro area and future Dakota County expansion.
Map NOTE:
Rebanded as of 4/9/08
Primary |
Alternate |
Alternate |
853.4875 |
852.4875 |
852.9875 |
Voice channels: 851.4875, 851.9875, 852.225, 853.900
Tower 106 / 262 - Isanti County (WPKG360) -
Backbone system for stage agencies in northern metro area and future
Isanti/Chisago County expansion. Map
Rebanded as of 4/08
Primary |
Alternate |
Alternate |
852.4625 |
860.2625 |
853.05 |
Voice channels: 859.2125, 852.150, 853.450
Tower 107 / 263 - Washington County (WPKG359) - Backbone system for stage
agencies in east metro area and future Washington County expansion.
Map NOTE: Rebanded as of
4/9/08
Primary |
Alternate |
Alternate |
853.7375 |
852.7875 |
853.1875 |
Voice channels: 855.9375, 851.1125, 851.3625, 851.7125, 852.125, 852.425
Tower 108 / 264 - Old Dakota County (WPKG310) - Former
WCAL standalone site, replaced by T103 full system.
Tower 109 / 265 - Minneapolis City (WPKH290) NAC
409 - Primary coverage for City
of Minneapolis users and U of M Mpls campus. Map
Rebanded as of 4/30/08
Primary |
Alternate |
Alternate |
Alternate |
852.0375 |
852.1375 |
868.6625 |
853.8125 |
Voice channels: 851.0375, 851.0625, 851.2375, 851.3375, 851.4625, 851.6375, 851.7375, 851.8625, 852.2375, 852.3375, 852.5625, 852.6375, 852.7625, 853.0375, 853.1625, 853.5125, 853.6625
Tower 118 / 280 - Future Winona/Austin area
866.0375, 866.0625, 866.2375, 866.3375, 866.4625, 866.6375, 866.7375, 866.8625, 867.2375, 867.3375, 867.5625, 867.6375, 867.7625, 868.0375, 868.1625, 868.5125
Tower 121 / 115 (Hex) - ? 852.4375 Possible future Scott
Co or Wright Co ?
Tower 122 / 116 (Hex) - ? 851.4375 Possible future Scott Co or Wright Co ?
Tower 123 / 117 (Hex) - ? 853.7875 Possible future Scott
Co or Wright Co ?
Tower 124 / 118 - Little Falls (WQDF220) - Primary coverage for Little
Falls and partial Morrison County area..
Primary |
Alternate |
Alternate |
860.9375 |
858.9375 |
859.9375 |
Voice channels: 856.9375, 857.9375
Tower 125 / 119 (Hex) - Lonsdale Rice Co (WQDH377 / WQHG475) -
Primary coverage for Rice Co, Goodhue, and Steele Co. Rebanded
as of 4/08
Primary |
Alternate |
Alternate |
851.975 |
852.300 |
Voice channels: 851.375, 852.550, 852.875,
853.675
Tower 201 / 513 - Hennepin East (KAA517) NAC
40F - Primary coverage for
Hennepin County users, east Hennepin County. Map
Rebanded as of July 08
Primary |
Alternate |
Alternate |
Alternate |
852.3625 |
852.1625 |
852.2875 |
853.8375 |
Voice channels: 851.0875, 851.2125, 851.5375, 851.6125, 850.7875, 852.1125, 852.475, 852.5375, 852.7375, 852.8375, 852.9625, 853.2625, 853.4375, 853.5375, 853.1625, 856.0125, 857.9625, 858.7125, 858.9625, 859.9625
Tower 202 / 514 - Hennepin West (WPKK355) - Primary coverage for
regional western Hennepin County, Wright County, northern Carver County.
Map Rebanded
as of July 08
Primary |
Alternate |
Alternate |
Alternate |
852.6125 |
852.2625 |
853.6375 |
853.8875 |
Voice channels:
Tower 203 / 515 - Ramsey County / Saint Paul system (WQBT680) NAC
40D - Primary
coverage for Ramsey County and City of Saint Paul. Map
Rebanded as of July 08
Primary |
Alternate |
Alternate |
Alternate |
852.0875 |
853.3625 |
853.7125 |
853.7625 |
Voice channels: 851.1875. 851.2875, 851.5875, 851.6625, 851.8125, 852.3125, 852.6875, 852.7125, 852.850, 853.2125, 853.2375, 856.4625
Tower 213 / 20D (Hex) / 526 (dec) - Stearns Kimball (WPKG276) - Stearns
County south.
Primary |
Alternate |
Alternate |
866.9875 |
868.675 |
Voice channels: 852.250, 852.4875, 852.900
Tower 214 / 20E (Hex) - Unknown, possible Henn Co SO mobile repeater
Primary |
Alternate |
Alternate |
868.9375 |
Voice channels:
Tower 215 / 20F (Hex) / 527 (dec) - Stearns Farming (WQCR302)- Stearns
County southeast.
Primary |
Alternate |
Alternate |
868.300 |
867.450 |
867.850 |
Voice channels: 855.7125, 866.200, 867.125
Tower 216 / 210 (Hex) / 528 (dec) - Stearns Avon (WQCR302)- Stearns
County northeast.
Primary |
Alternate |
Alternate |
868.275 |
866.225 |
866.625 |
Voice channels: 856.2125, 867.050, 868.650
Tower 217 / 211 (Hex) / 529 (dec) - Stearns Grove Township/Melrose (WQCR302) - Stearns County northwest.
Primary |
Alternate |
Alternate |
866.375 |
859.4875 |
860.4875 |
Voice channels:
Tower 218 / 212 (Hex) / 530 (dec) - Stearns Belgrade (WQCR302) - Stearns County southwest.
Primary |
Alternate |
Alternate |
868.0625 |
859.7125 |
860.7125 |
Voice channels: 857.7125, 858.7125
Tower 219 / 213 (Hex) / 531 (dec) - Saint Cloud (WNRI487)
NAC
405- Primary coverage for St Cloud &
Stearns County users.
Primary |
Alternate |
Alternate |
Alternate |
860.4625 |
857.9875 |
857.4375 |
856.4375 |
Voice channels: 855.4625, 859.4625, 867.300
Tower 220 / 214 (Hex) / 562 (dec) - Olmsted/Rochester (WQCT910)- Primary coverage for Rochester &
Olmstead County users. Rebanded as of 4/08
Primary |
Alternate |
Alternate |
Alternate |
853.6125 |
Voice channels:
Tower 340 / 328 (Hex) - ? 851.425
Tower 341 / 329 (Hex) - ? 853.6125
Tower 405 / 405 (Hex) / - Benton Co Gilman (WQDJ739)- Primary coverage for Benton Co, Gilman area
Primary |
Alternate |
Alternate |
Alternate |
851.900 |
852.400 |
Voice channels: 851.425, 851.800, 852.875, 853.525
