Nov 13 Chapter
9 Patterns of Inheritance (continued)
ii) genetic
recombination
In reality, F2 generation always contains a small
proportion of recombinant phenotypes due
to crossing over.
Crossing over produces new combinations of alleles
(Fig 9.19A, p175).

In
the example of sweet pea plants, crossing over would produce gamete genotypes
such as Pl and pL.
As
a result, about 10 % of F2 generation shows recombinant phenotype (Fig 9.18,
p174).
Can
you identify recombinant phenotypes in the Fig 9.18?
iii)
recombination frequency vs. genetic map
Recombination frequency -
the percentage of recombinants in offspring.
Recombination
frequency (%) =
(number
of recombinant / total number of offspring) x 100
ex. Fig 9.18
number of recombinant 21 + 21= 42
total number of offspring 284+21+21+55= 381
recombination frequency 42 / 381 = 11 %
-
Recombinant frequency is higher between genes located further apart in the
chromosome.
-
Physical distances between gene loci can be estimated via recombination frequency
(Fig 9.20, p176) ® Genetic map
Example:
If recombination frequencies between three genetic
loci A, B and C are
A and B 20 %
B and C 15 %
C and A 5 %
Genetic map of
loci A, B and C would be:
f.
sex-linked
genetic disorders
i) determination
of sex
-
Many (but not all) animals have two
separate sexes.
-
Many (but not all) animals that have
sexes contain sex chromosomes.
-
Human sex is determined by X and Y
chromosomes (the X-Y system, Fig 9.21A, p177).
XX
– female
XY
– male
The Y chromosome carries
genes necessary for male development.

<Sex
determination in other animals>
Fruit
fly: XX – female XY – male
Crickets,
grasshoppers: XX – female XO –
male
Bird,
butterflies: ZW
– female ZZ – male
Bee,
ants: diploid
– female haploid – male
- Some
animals can develop into both male and female.
- Some
animals and most plants do not have separate sexes at all. Individuals produce both male and female
sexual organs.
ii) sex-linked genetic disorders
-
Red-green color blindness, hemophilia
and Duchenne muscular dystrophy are examples of sex-linked genetic disorders.
-
They are localised on the X
chromosome and exhibit a unique pattern of inheritance.
-
These disorders affect mostly males.
Sex-linked
alleles
XA
– dominant allele
Xa
– recessive allele
Example: Red-green color blindness Xcb
Xcb – color blind allele XCB
– normal vision allele
Genotype of
a female carrier: XCBXcb
Genotype of
a normal male: XCBY
Children of
a female carrier and a normal male:
Genotype
|
|
XCB |
Xcb |
|
XCB |
XCBXCB |
|
|
Y |
|
|
Phenotype
|
|
XCB |
Xcb |
|
XCB |
normal female |
|
|
Y |
|
|
Probability
of a female child being color blind:
Probability
of a male child being color blind:
5) Genetic testing
- Genetic testing is becoming more and more
common.
- > 900
genetic disorders can be tested today.
- Detects
presence and absence of defective alleles or genetic markers.
- The
presence of a defective allele does NOT mean the person has the disease.
ex1. A person with the Huntington’s disease allele
may not develop the disease
until
later in life.
ex2. A person with a breast cancer gene has a
higher risk of developing breast
cancer
but that does not mean that she has cancer.
Different types of genetic testing
a. Diagnostic testing allows
accurate diagnosis of patients showing symptoms.
b. Newborn screening is
detection of genetic disorders immediately after birth. It allows affected infants to receive
immediate medical attention.
ex.
Phenylketonuria (PKU): Defect in metabolism of amino acid phenylalanine. Requires nutritional restrictions all through
life.
c. carrier testing
d. prenatal testing (fetal testing)
e. predictive testing
Priya
Should Find Out She Inherited a Fatal Disease (or should she?)
Priya has just lost her mother to an illness called
Huntington’s disease. It was hard for Priya to watch her mother die. First her mother
had strange changes of mood. Then her arms and legs began twitching. Soon she
couldn’t talk or control her movements. In the end, she was totally bedridden
and could barely get food down without choking. Priya knows that Huntington’s
disease usually strikes people in middle age. It is always fatal, and there is
no treatment. She also knows that since the disease is inherited, she has a
strong chance of getting it herself. Priya just learned about a test she can
take. The test will tell if she carries the gene for Huntington’s disease. She
is tempted to take the test. She thinks that if she could find out once and for
all whether she will get the disease, she could plan for her future. On the
other hand, she wonders if it is better not knowing. At least then Priya would
still have some hope. If you were Priya, what would you do?
<Huntington’s
disease (HD)>
-
Autosomal dominant.
o
The probability of Priya inheriting
the HD allele from her mother is 50 %.
-
Develop in midlife.
-
Persons with HD may show
uncontrolled movement. They lose thinking
ability and motor skill over the course of disease (10 – 20 years).
-
No effective treatment available.
Predictive testing –
Genetic testing of individuals showing no symptoms. Access the person’s risk of developing the
disease.
Genetic counselling
-
The result of genetic testing can be
devastating.
-
There is no way of predicting how
you will react to positive or negative reactions.
-
The test procedure and results
should be explained thoroughly by professional advisors.
-
Genetic
counsellors help them clarify genetic testing and cope with
the test results. They may suggest
appropriate support (counsellor, support group, etc) to the individuals after
the test.
Why
do you think Priya wants to have her genetic testing long before her symptoms
appear?
How
do you think she would respond to the positive (i.e. she has the HD allele) or
negative result (i.e. she does not have the HD allele)?
If
she gets the positive result, who should she share the result? Her family?
Her employer? Her insurance
company?
If
she gets the positive result, should she have children? There are different options for having
children.
Carlos
and Mollie Can Have a Perfectly Healthy Baby (or can they?)
Carlos and Mollie want to have children. However,
they haven’t tried to start a family yet because they disagree on something important.
Carlos wants Mollie to get tested to see if she is a carrier for cystic
fibrosis (CF). Mollie doesn’t want to do it. People with CF have mutations in
one or more genes. These mutated genes give faulty instructions for the
production of proteins that help move salt in the body. One result is that the lungs
become clogged with mucus, making it hard to breathe. Another result is that
the body has a hard time digesting food. The disease can be painful and lead to
an early death. Carlos had a brother with CF. He hated seeing his brother
suffer so much. His parents struggled with the hardship and expense of caring
for a sick child who never made it to adulthood. Carlos doesn’t want to repeat
that experience in his own life. That’s why he had himself tested for CF.
Unfortunately, he found out that he is a carrier. CF is a recessive disorder.
That means his children will have the disease only if they inherit the mutated
gene from both parents. Mollie can get tested to see if she carries the CF
mutation. If she does, then when she gets pregnant they can have the fetus
tested to make sure it does not have two CF genes and is therefore free of the
disease. Mollie would prefer simply not knowing what the risks are. She figures
that once a baby is in their arms, they will be glad they had it, no matter
what. If you were Mollie or Carlos, what would you do?
<Cystic fibrosis (CS)>
-
Autosomal
recessive
o
If both
parents are carrier, the chance of their child getting CS is 25 %.
-
Most
common fatal genetic disorder
-
Children
with CS have difficulty breathing or digesting food.
-
Vulnerable
to infections
-
The
affected children may or may not make to the adulthood.
Carrier
testing – Genetic testing to determine
whether the person is a carrier of a
recessive genetic disorder.
If Mollie turns out to be a carrier of the CF
allele, what are their options?
-
They may
decide not to get married.
-
They may
decide not to have children. They may
want to adopt children instead.
-
They may
decide to have fetus tested while Mollie is pregnant (Prenatal testing).
-
If the
fetus has CF, they may decide to terminate pregnancy.
-
They may
consider in vitro fertilization. Sperms and eggs are fertilized in a petri
dish. Obtained embryos can be tested for
presence of the CF allele. The embryos
that do not carry the CF allele are implanted to mother’s uterus. Very expensive procedure. High failure rate.
Even if they try everything to avoid a child with
CF, they may still be end up with a sick child.
Even if they have a child with CF, advancement of
medical research may provide him/her a better quality of life.
Howard’s
Health Is Up to Him (or is it?)
Howard will turn 50 soon, and it worries him. His
grandfather died of a heart attack in his fifties, and so did his father and uncle.
Several years ago, a doctor told Howard that he was at high risk for heart
disease because of his family history. But the doctor said that Howard could
improve his chances if he lost some weight, stopped smoking, and exercised. The
doctor also told Howard to come back every year for a checkup. Howard hasn’t
gone on a diet, and he hasn’t given up his cigarettes or taken up exercise. He
also hasn’t been back to the doctor. He’s afraid of what the doctor might find.
Howard can’t make up his mind. Sometimes he thinks he should try to take better
care of his health. Other times, he thinks that he should just accept the fact
that he won’t live much longer and should get as much fun out of life while he
can. If you were Howard, what would you do?
