Partial patchwork mosaic of the Perseus cluster.
10 images cover approx 40x60 arcmin
01/27/2003 21:36-22:16 EST
Each frame 3x60sec
TouCam SC1.5 webcam peltier/water cooled (-25C, ambient -14C)
Dark+flat generated by stacking 1 frame of each un-registered
10inch lx200 F10 @ F3
Captured via AV scripting, Processed in IRIS
Mosaic in PictPub
Annotation data determined with the use of
NED and its links to
Aladin
Click here for a 2600x1600 view with 77+ annotations
Abell-426 - the Perseus cluster
Reference page - click here
All images and text Copyright 2003 by the author
