BLOCK, CRANK, PISTONS AND RODS
- 1969 351 WINDSOR BLOCK 4.030" Bore
- Stock 1969 Crank, .010/.010 3.500"Stroke
- Trick Flow forged Steel Rods
- ARP Rod Bolts across all internals
- Clevite77 Main Bearings
- Clevite 77 Rod Bearings
- TRW L-2446-F Forged Pistons (+.030")
- Hastings Moly Rings
- Balanced Assembly, Flycut forged Pistons
- Stock 1969 Crank, .010/.010 3.500"Stroke
- Trick Flow forged Steel Rods
- ARP Rod Bolts across all internals
- Clevite77 Main Bearings
- Clevite 77 Rod Bearings
- TRW L-2446-F Forged Pistons (+.030")
- Hastings Moly Rings
- Balanced Assembly, Flycut forged Pistons
INDUCTION &
FUEL
- Edelbrock Performer RPM Intake Manifold,
Ports matched
- Speed DeMon 750 CARB with mechanical secoondaries
- Summit Racing 140 gph Electric Fuel Pump
- Summit Racing Fuel Filter 390 gph reusaable 60 micron element
- ½ inch phenolic resin carb spacer
- RAM Air with K&N 14x 3 plus X-stream lid
- 5-12 psi Fuel Regulator with Gauge
- Stainless braided line 3/8 with aircraft NTP 6 and 8 fittings
- Speed DeMon 750 CARB with mechanical secoondaries
- Summit Racing 140 gph Electric Fuel Pump
- Summit Racing Fuel Filter 390 gph reusaable 60 micron element
- ½ inch phenolic resin carb spacer
- RAM Air with K&N 14x 3 plus X-stream lid
- 5-12 psi Fuel Regulator with Gauge
- Stainless braided line 3/8 with aircraft NTP 6 and 8 fittings
HEADS
-World Products Windsor Sr. High Performance
Cast Iron Heads, Ported
- 2.020x1.600 Manley Street-Flo Stainless valves
- 64cc fast burn shape combustion chambers, Umbrella style Valve seats
- 200cc Intake Runners, 2.00x 1.12 port dimension
- 64cc Exhaust Runners, 1.30 x 1.22 port dimension
- Integral Steel Valve guides
- Hardened Steel Pushrod guideplates
- 7/16 top x 7/16 bottom Rocker arm studs
- ARP ½ head bolts with washers, FEL-PRO HHead Gaskets
- 2.020x1.600 Manley Street-Flo Stainless valves
- 64cc fast burn shape combustion chambers, Umbrella style Valve seats
- 200cc Intake Runners, 2.00x 1.12 port dimension
- 64cc Exhaust Runners, 1.30 x 1.22 port dimension
- Integral Steel Valve guides
- Hardened Steel Pushrod guideplates
- 7/16 top x 7/16 bottom Rocker arm studs
- ARP ½ head bolts with washers, FEL-PRO HHead Gaskets
LUBRICATION
- Steel Oil Pan with Windage Tray
- Melling M83HV High Volume Oil Pump
- ARP #154-7901 Hardened Oil Pump Drive Shaft
- ARP pan bolts
- Melling M83HV High Volume Oil Pump
- ARP #154-7901 Hardened Oil Pump Drive Shaft
- ARP pan bolts
CAMSHAFT
- Competition Cams 1.6 Magnum Rolller Rocker Arms
- Crane Roller Lifter Kit
- Crane Hardened push Rods
- Crane Roller CAM 282/290 220/228/.542/.5563 112LC
- Edelbrock Double Roller Timing Chain
- F P.A.: 1 3/4" primaries
- 15/8-13/4 step design
- 3 1/2" collectors,
- 3/8 flanges, 16 gauge one-piece design
- hardened nickel chrome finish.
- CSI Electric Water PUMP
- MrG - 16 Electric FAN
- STANT THERMOSTAT 180 deg F.
- Digital temp reading with fan relay set to 185 deg. F
- 4 Row 24 Radiator
- Mallory UNILITE Opto-Electronic distributor
- MSD -6AL IGNITION with 7000 RPM limiter
- MSD Blaster SS Coil 40 000 Volt spark eenergy
- FORD MOTORSPORT Distributor gear
- MOROSO SuperMax 11 mm sparkplug wires W/ 115 deg. boots
- Hays Billet Flywheel
- Centerforce Clutch and Pressure Plate
- Summit Racing Harmonic Damper SFI 18-1, 28 oz
- March under-drive crank pulley 5 Ό
- Powermaster 80A one wire Alternator
- Toll Ford Motosport Valve Covers with K&N breathers
- ARP Stainless steel 6 point engine bolts and FEL-PRO Gasket set
