- 360° Virtual-World Imaging
- Kelvin Chew Tiong Meng
- B.Eng. Final Year Project 2000/2001
- The University of Birmingham
- School of Electronic & Electrical Engineering
- 3. Collection of Mosaics:
-
-
-
- 1. DOM (Cathedral) in Koln, Germany
- These pictures were taken before I started my project, and
had no prior knowledge on image mosaicing. Thus, the images taken
had atrocious roll angle errors and a large difference
in exposure. Nevertheless, I tried merging them using
my software and it was successful but with some visible aliases.
-
-
Completed Mosaic
 |
-
-
-
- 2. Pipe Organ in Great Hall, University
of Birmingham
- The 2 images were taken without the use of a tripod. Notice
the right image has a CCW roll angle error. This explains
the rotated final mosaic.
-
-
Completed Mosaic
 |
-
-
-
- 3. Aston Webb, University of Birmingham
- Frontal view of Aston Webb Building consisting of 4 images.
-
-
Completed Mosaic
 |
-
-
-
- 4. The Vale, University of Birmingham
- Mosaic created from 4 images of the Vale, University of Birmingham.
The final mosaic is part of the 360degree panorama of the Vale
on the Main page.
-
-
Completed Mosaic
 |
-
