Messerschmitt Bf-109G-2 Instrument Panel Layout

1. Ammunition Counter (Middle is Cannon) 9. Bank, Pitch, Artificial Horizon Indicator
2. Gun Site 10. Speedometer in Km/h
3. Clock 11. Manifold Pressure Gauge
4. Magneto 1 and 2 Switches 12. Tachometer
5. Landing Gear Lights 13. Propeller Pitch Indicator
6. Spark Plugs Warning 14. Engine Temperature in Celcius
7. Compass and Radio Direction Finder 15. Fuel Warning Light
8. Altimeter in Meters 16. Fuel Gauge
17. Oil Pressure Gauge
