| 1970 SCOUT 800A SPECIFICATIONS |
| 232 I 6 Engine (86,000 miles) T-90 3-speed tranmission (manual) Dana Model 20 Transfer Case Dana 44 Rear Dana 30 Front (closed knuckle) both 3:73 ring & pinion with open differentials. |
| Lift |
| Drivetrain |
| Spring over axle with stock 1 3/4" wide leafs 1 1/2" lift shackles Rancho 9012 long travel shocks (1 per wheel) Fits 33" Buckshot bias ply mudders without any rubbing or fender trimming. |
| Steering |
| Manual stock setup with the exception of: Gryphin Racing tie rod Pitman arm from a 4-cylinder Scout 800 |
| Brakes |
| This vehicle (like our webpage) is always under construction but still functional! |
| Stay tuned for future updates. |
| Click these links to visit our other pages: |
| Manual drums on all 4 corners New lines from the Master Cylinder on back. Custom length (27" stainless hoses from Goodridge USA. |
|
 |
 |
 |
 |
