Drawings required: plans for all levels
at least two cross-sections
at least two exterior elevations
one exterior or interior perspective or axonometric drawing
3-D required: model cancelled!!!... thank God, can't imagine having to actually built the thing!
Due date: October 30, noon
Drawings required: plan (1/4 scale)
site plan (1:20 engi scale)
two 1/2" cross sections
1/4" longitudinal section
3-D required: model (1/4 scale)
Due date: extended to November 6.... story!
