An-22 Antei Cock



An-22 Antei Cock


It is not widely realized that the largest airplanes in the world come from Ukraine. The Antonov Design Bureau in Kiev, Ukraine has produced a series of airplanes able to claim the title of biggest airplane in the world.

The largest production airplane in the world from 1965 until the introduction of the Lockheed C-5A Galaxy in 1969. 66 Constructed. A number are still in service with the V-TA and one is used by Antonov to transport An-124 wings attached along the top of its fuselage. In Greek mythology, Antheus was a giant whose great strength depended on keeping his feet in contact with the ground.

The first An-22 flew on 24 February 1965, and it was publicly displayed at the Paris International Air Show at Le Bourget the same year. The largest transport aircraft of the time, An-22 set a number of world records. Despite orders for 100 An-22, only 48 aircraft were actually flying by 1983.

This is it: The worlds largest propeller driven aircraft ever in daily use. Despite the fact, that all but one (known) Antonov An-22 fly in civil markings, i.e. mostly Aeroflot colors and titles, the aircraft serves as a military transport. With the end of the Warsaw Pact and related supply flights to Sovjet bases in Central and Eastern Europe, demand for the heavy lifting capabilities of the An-22 has weakend considerably.

Roughly 100 An-22 have supposedly been built. The majority of them is still based on two large Air Force bases within one hour of flight from Moscow. They are Tver Migalovo to the Northwest of the capital, along the road Moscow - Sankt Peterburg, and Ivanovo to the Northeast of Moscow.

According to Russian Air Force officials, it is expected that each of the two bases will maintain about a dozen of the huge birds active in the years to come.

Antonov An-22 Antheus (Cock)

Country Of Origin: Ukraine
Designation: Heavy military transport
Aircraft Crew: Two pilots, a flight engineer,
navigator and radio operator
Transport Capacity: 28 passengers

Aircraft Dimensions:
Length: 190 ft (57.9 m)
Wingspan: 211 ft 4 in (64.4 m)
Height: 41 ft 1in (12.5 m)

Aircraft Weights:
Empty: 251,325 lb (114,000 kg)
Max T/O: 551,160 lb (250,000 kg)

Aircraft Performance:
Max Speed: 460 mph (740 km/h)
Range: 5,905 nm (10,950 km); 2,692 nm
(5,000 km) with max payload
Powerplant: four Kuznetsov NK-12MA
turboprops
Thrust: 60,000 shp (44,740 kW)
Payload: 176,350 lb (80,000 kg)

Aircraft Armament:
None

Aircraft Variations:
None



Sources

The info for this plane was taken from the following sources on the internet and all credit should go to them. If you want to know more about this aircraft, I suggest checking out these great sites.
An-22 Antei Flown To A German Museum
Military Analysis Network
North American Special Operations Group
An-22, O.K.Antonov 'Antej' (Antheus) 'Cock'
An-22 Antei Cock (Russian)
Goleta Air and Space Museum
A Guide to Russian Airliners
