KENSINGER KF
Specifications
ENGINE
(1953-1968) Four cylinder, Teledyne-Continental C85-8FJ of 90 hp at 2750 rpm.
(1968-) Four cylinder, Rolls Royce Continental 0-200 (Mod) of 110 hp at 2850 rpm.
PERFORMANCE
|
Max Speed in Level Flight |
200 mph |
|
Cruise Speed (80% Power) |
180 mph |
|
Vne (Maximum Speed) |
250 mph |
|
Range at 80% Power |
435 miles |
|
Rate of Climb |
1700 fpm |
|
Service Ceiling |
17,000 ft |
|
Stall Speed (No Flap) |
65 mph |
|
Stall Speed (Full Flap) |
60 mph |
|
Take Off Distance |
570 ft. |
|
Landing Distance |
680 ft. |
|
Roll Rate |
3600/sec |
|
Max Load Factor |
+6 g, -4.5 g |
WEIGHTS
|
Empty Weight |
605 lbs. |
|
Gross Weight |
997 lbs. |
|
Wing Loading |
14.0 lbs/ft2 |
|
Power Loading |
9.5 lbs/hp |
|
Fuel (Fuselage Tank) |
12 Gallons |
|
Fuel (Wing Tanks) |
8 Gallons |
|
Baggage |
30 lbs. |
DIMENSIONS
|
Wing Span |
18 ft. 6 in. |
|
Length |
16 ft. 5 in. |
|
Height (Tail Down) |
4 ft. 6 in. |
|
Wing Area |
68 ft2 |
|
Wheel Track |
5 ft. 1 in. |
