Specification F1 91
| Engine: | Rear-mounted 60° V12, special cast iron cylinder block without wet liners, light alloy head, water cooled. |
| Bore & Stroke: | 86 x 50.2 mm |
| Unitary and Total Displacement: | 291.6/3,499.2 cc |
| Compression Ratio: | 13:1 |
| Max. Power Output: | 710 bhp at 13,800 rpm |
| Timing Gear: | 5 valves per cylinder (3 intake), 2 overhead camshafts, gear driven off the front of the engine |
| Fuel Feed: | Weber-Marelli digital electronic injection with twin injectors per cylinder |
| Ignition: | Single plug, Magneti Marelli electronic |
| Lubrication System: | Dry sump |
| Transmission: | Rear-wheel drive, three-plate carbon clutch with mechanical and automatic control, rear longitudinal overhanging 7-speed gearbox + reverse, automatic with electronic management, ZF limited-slip differential |
| Gear Ratios: | Variable depending on track |
| Chassis: | Monocoque in composite: carbon-fibre and Kevlar honeycomb |
| Front Suspension: | Double elliptic section wishbones, push-rods |
| Rear Suspension: | Double wishbones, push-rods |
| Brakes: | Ventilated outboard carbon-fibre discs, Brembo one-piece 4-pot callipers |
| Steering: | Rack and pinion |
| Length: | 4,400 mm |
| Width: | 2,130 mm |
| Height: | 1,004 mm |
| Wheelbase and Front/ Rear Track: | 2,881/1,800/1,675 mm |
| Kerb Weight (with water and oil): | 505 kg |
| Front Tyres: | 25x10", Goodyear |
| Rear Tyres: | 26x15", Goodyear |
| Fuel Tank: | 215 litres, with 1 centre and 1 side tanks, 102 RON fuel |
| Bodywork: | Composite, detachable |
