| MODEL | POLES | VOLTAGE | FREQUENCY | OUTPUT | RATED | STARTING TORQUE | TEMP-RISE | WEIGHT | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| SPEED | TORQUE | CURRENT | |||||||||
| P | V | Hz | W | R.P.M. | Kg-cm | A | kg-cm | deg | Kg | ||
| IS-8415 | 4 | 100 | 60 | 2.31 | 1500 | 0.15 | 0.26 | 0.10 | 50 | 0.90 | |
| IS-8420 | 4 | 115 | 60 | 8.87 | 1600 | 0.54 | 0.56 | 0.25 | 55 | 1.10 | |
| IS-8440 | 4 | 220 | 60 | 14.4 | 1650 | 0.85 | 0.49 | 0.35 | 55 | 1.70 | |
