My Corolla


MODEL TOYOTA COROLLA
1998 1.6 GLi
4-Speed Automatic

Engine

Model 4A-FE
Type 4 Cylinder-in-line, DOHC 16-valve, EFI
Engine Displacement: cc 1,587
Bore and Stroke:  81.0 x 77.0
Compression Ratio: 9.5:1
Max. Output: Hp / rpm 110 / 6,000
Max. Torque: Nm / rpm 145 / 4,800
Fuel System: EFI (Electronic Fuel Injection)

Chassis

Suspension: Front / Rear Independent MacPherson Strut with Stabilizer Bar
Brakes: Front / Rear Ventilated Discs / Drums
Tires: 185 / 65 HR14
Wheels: 5.5J x 14

Steering System

Type Rack and Pinion with Power Steering
Steering Wheel: 4-Spoke Urethane
Steering Column: Tilt Adjustable Fixed

Dimensions & Weight

Overall LxWxH: mm 4,395x1,690x1,385
Wheelbase: mm 2,465
Tread Front / Rear: mm 1,460 / 1,450
Ground Clearance: mm 150
Curb Weight: kg 1,060
Trunk Room: L 417
Fuel Tank Capacity: L 50
Min. Turning Radius: m 4.8

Exterior

Headlamps: Multi-Reflector Halogen
Radiator Grille: Chrome-Plated
Bumpers: Color Keyed
Front Windshield: Tinted Laminated
Window Sash Blackout: With
Side View Mirrors: Power Remote Control, Color Keyed
Door Handle: Color Keyed
Side Protective Moldings: Color Keyed
Mudguards: Color Keyed
Side Skirt With: (Dealer Option) Without
Rear Defogger: With
Antenna: Manual
Rear Plate: Color Keyed
Catalytic Converter: Without

Interior

Power Windows and Door Locks: With
Digital Clock: With
Meter Illumination Control: With
Key Warning Buzzer: With
Light Warning Buzzer: With
Cup Holder: Retractable, Two Cups
Accessory Box: With
Center Cluster Box: With
Center Console Box: Dual with Lid (Full Fabric)
Front Door Pocket: Large, 2 pcs.
Sunvisors With Vanity Mirror: With
Seats Front: Reclining Seats w/ Adjustable Headrests, Height Adjustable Lumbar Support
Rear: 60/40 Split, Adjustable Headrests Fixed
Seat Belt Anchor: Adjustable
Seat Back Pocket: With
Seat Material: Moquette (Full Fabric)

Safety

Reinforced Cabin (Twin Side door Beams) Standard
ABS 4-Wheel
SRS Airbags Electronic, Driver and Passenger
Seatbelts Front  3 Pt. ELR x 2 pcs. with Pretensioner and Force Limiter
Rear 3 Pt. ELR x 2 pcs. and an NR Center Lapbelt
High Mount Stop Lamp: With
Power Window with Jam Protection: With (Driver)

Options

Airconditioning System: Nippondenso 4-Speed Air Blower with Dial Type Controls
Audio System: Alpine Radio/Cassette Player (Full Logic)Front (4 pcs.) and Rear (2 pcs.) Speakers Toyota Vehicle Security System: With
