Dynaflite Fun Fly 51

Span 50" 493 Sq"

Equipment
Aveox 1406/4Y with Astro 2.38 Gearbox
Prop APCE 12x10 3” Black Spinner
ESC Jeti Hacker Master 40-3P Opto

TP 4S4P LI-PO
UBEC & Li-Saver
Hi-Tec 555 RX
2 Hi-Tec HS 81’s Servo's in rear
2 Hi-Tec HS 81’s for Ailerons

Modifications
Converted from Glow to Electric
Polyester Dress Liner covering with SIG silver dope Upper surface & black lower
Wheels Robbe 2 3/4 Wheels
RA Tail Wheel
4S4P Li-Po

Total Weight ready to fly 74.0 oz.

Wing Incidence 0 at root 0 at Tips
Motor offset 0 down 0 left & right
CS Throws R – 1/2 E – 1/2 A – 3/8 U 1/4 D
Run Up Starting Volts 16.2 – Amps 29.5 – Watts 435 - estimating 16 minutes full throttle

Ready to fly 9/13/04
