Warspite II Class
SSBN
�Copyright
Specifications:
Powerplant: 1 x DD 16V 396 diesel engine, 3.12 MW / DD(Doujin Defense) AIP (Air Independent Propulsion) system, 300 kW
Displacement: 45,000 Tons (Empty) 53,000 Tons (Fully Loaded)
Dimensions: 205M L x 56M W x 43M H
Speed: 34 kts (Sufaced), 32 kts (Submerged)
Propulsion: M-Drive ("Caterpillar Drive")
Crew: 120; Officers: 25
Armament: 5 x 21" (660MM) Torpedo Tubes, 30 Trident 'DF' SL-ICBM Tubes (Can be replaced with six cell rotary launchers for Tomahawk SLLAM or equivalant - 180 missiles)
Systems:
C3I-Command, Control, Communication, and Intelligence
C3I will integrate sensors, countermeasures, navigation, and weapon control
Displayed on color display consoles
Radar: BPS 16 for navigation
Fire control system: Will be based on Raytheon MK 2
Sonars: Doujinshi Advanced Spherical active/passive arrays
Light Weight Wide Aperture Arrays
TB-16, TB-29, and future towed arrays
High-frequency chin and sail arrays
MOA 3070 mine detection sonar
Photonic Masts - Two AN/BVS-1 Photonic Masts.
Advantages of using Photonic Masts:
Non-Hull Penetrating
Includes low light TV, a thermal imager, and a laser range finder
Two workstations
Photonics mast workstation and Command workstation
Two displays on each workstation
Upper display for real time video
Lower display for real time, recorded, or still frames
A handgrip is used to control the sensor head, select views, select contacts, and take still frames
Price: 2.9 billion
|
