PS2 Specification

PS2 Specification
Product Name PlayStation2
Accessories

» Dual Shock 2 analog controller
» 8MB Memory Card
» PlayStation2 Demo Disc
» AV Multi cable
» AC power cord

Dimensions 301mm (W) X 178mm (D) X 78mm (D)
Weight 2.1Kg (4lbs)
Media PlayStation2 CD-ROM, DVD-ROM, PlayStation CD-ROM
Formats supported Audio CD, DVD-Video
Interfaces » 2 Controller ports
» 2 Memory Card slots
» 1 AV Multicable output
» 1 Optical digital output
» 2 USB ports
» 1 i.Link (IEEE1394)
» 1 Type III PCMCIA card slot
Specifications » CPU : 128 Bit "Emotion Engine"
» System Clock Frequency : 294.912 MHz
» Main Memory : Direct RDRAM
» Memory Size : 32MB
» Graphics : "Graphics Synthesizer"
» Clock Frequency : 147.456MHz
» Embedded Cache VRAM : 4MB
» Sound : SPU2
» Number of Voices : 48ch plus software
» Sound Memory : 2MB
» Sound frequency : 44.1 kHz or 48 kHz
» Supports : Dolby, AC3, and DTS
» IOP : I/O Processor
» CPU Core : PlayStation CPU+
» Clock Frequency : 33.8688MHz or 36.864MHz (Selectable)
» IOP Memory : 2MB
» Disc Device : CD-ROM and DVD-ROM (CD-ROM 24x / DVD-ROM 4x)
