Wheelchair Lift Specifications

Power Dock Lift (700-PD)

• Carries various power wheelchairs that do not exceed 325 lbs.
• Corrosion resistant, brushed aluminum rails. (2) 8" x 47 1/2"
• (1) Automatic docking station.
• (1) Docking adapter. Attaches to certain power chairs.
• Overall weight (without accessories): 108 lbs.

Power Chair Lift (600-PC)

• Carries most power wheelchairs that do not exceed 325 lbs. Power chair must be less than 26" wide.
• Corrosion resistant, brushed aluminum rails. (2) 8" x 47 1/2"
• (4) Ratcheting hook straps.
• Overall weight (without accessories): 105 lbs.

Hoveround Lift (3OO-IN)

• Compatible with Hoveround MPV and LPV power wheelchairs.
• (1) 28" x 35 1/2" corrosion resistant, brushed aluminum platform.
• (4) Ratcheting hook straps.
• Overall weight (without accessories): 107 lbs.

Specifications:

• Heavy duty 12 volt DC motor: 35:1 gear ratio. Draws 8 amps under full load.
• 12 volt DC battery: Comes with 110 volt AC charger. Up to 150 cycles per charge.*
• Mechanical clutch/brake: Key-switch operation, no electrical switches. Comes with personal set of keys.
• Bolt-on hitch attachment: Allows lift to be easily transferred to other vehicles.

Available Accessories:

• Hardwire Kit: Lift can be wired directly to the vehicle's power source as an alternative to the on-board battery.
• Swing Away Joint: Allows access to the vehicle's trunk or tailgate, or rear doors on pick-ups, SUV's, or minivans by allowing the lift to be repositioned to the vehicle's side.
• License Plate Kit: Bolt-on frame relocates the vehicle's license plate for better view.

* Tested with 325 lbs. in ideal conditions. Number of cycles will vary depending on scooter weight, and climate.
