SAUNDERS
- ROE
SARO
SKEETER |
|
En 1951 SAUNDERS-ROE adquirió la compañía Cierva, a fin de introducirse en el campo de las alas rotativas. Cierva había puesto en vuelo el 8 de octubre de 1948 el prototipo de un helicóptero biplaza al que designó Cierva W.14 Skeeter I, y Saro prosiguió con el desarrollo de esta aeronave. Tres prototipos del Saro Skeeter 6, propulsados por un motor Gipsy Major 200 de 200 HP , fueron evaluados por el Ejército británico y ello resultó en el encargo de 4 helicópteros, construidos en forma de tres Skeeter AOP.MK 10 y un entrenador con doble mando Skeeter T.MK 11. El cuerpo aéreo del Ejército adquirió 64 helicópteros AOP. MK 12 Skeeter de serie, que diferian por que contaban con un motor Gipsy Major de 215 HP. Además bajo la denominación de Skeeter MK 50 y Skeeter MK 51 el ejército alemán y la marina utilizaron seis y cuatro aparatos, respectivamente. Estos aparatos tenían un rotor principal de 9,75 m de diámetro. Se previó una variente civil bajo la denominación Skeeter Serie 8, pero se construyó un único aparato. La cadena de fabricación se cerró en 1960 y para ese entonces Saunders-Roe había sido adquirida por Westland. |
|
The
Skeeters roots go back to 1948. It was the creation of 'The Cierva
Autogiro Company', called the 'W14 Sceptre' and it first flew on the
10th. October 1948. In
1951, 'The Cierva Autogiro Company' and its early prototype helicopters were
taken over by 'Saunders-Roe'; officially abbreviated 'SARO'. At the time,
Saunders-Roe were known for their flying boats and had no experience in
designing and building helicopters. They set up their new helicopter
division at Eastleigh and from there successfully developed the Skeeter from its
early prototypes to the definitive MK7 (Military designation - A.O.P.12). The
phenomenon of ground-resonance plagued the early prototypes but was eventually
cured, but only after taking the lives of two test pilots. The
Skeeter was the first Helicopter operated by the British Army Air Corps., it
replaced the Auster 9 in an observation and reconnaissance role and was also
used for training. The first deliveries were taken in 1959 and were
operated until the last one was struck off the military register in 1967.
In total there were 88 Skeeters built (including prototypes), the British Army
Air Corps took delivery of 77. At
the time of publication, there is only one flying example of the Skeeter in the
world.
The
Skeeter is a light, two seat, piston engine helicopter, wholly British designed
and built. It is of conventional configuration, having a single Main Rotor
and a tail rotor. The
Main Rotor system is 'fully articulated' and has three rotor blades. It
has a diameter of 32 feet and in cruise flight it revolves at 317rpm. At
this speed the tips are traveling close to 400mph. The job of the main
rotor is to provide lift and propulsion. Power
is produced by a deHavilland Gypsy Major 140 air cooled, 4 cylinder,
inline, fuel injected piston engine. The engine's cubic capacity is 6.90 litres,
and produces 215 b.h.p. The Skeeter has a tricycle undercarriage with a 'free castering' nose wheel. Thanks to skeeterheritage.co.uk |
|
Characteristics |
Information |
Characteristics |
Information |
First Flight Primer Vuelo |
1948 |
Engine Motor |
1 Gipsy Major 140 |
Seating Capacity Plazas |
1 / 1 |
Power Potencia |
215 HP |
Empty Weight Peso Vacío |
1750 Lb |
Hover Ceiling
O.G.E. Estacionario O.G.E |
NA |
Maximum
Weight Peso Máximo |
2350 Lb |
Hover Ceiling
I.G.E. Estacionario I.G.E |
NA |
Vel. Cruise Vel. crucero |
78 Kts |
Service
Ceiling Techo de Servicio |
12800 Ft |
V.N.E. V.N.E |
105 Kts |
Maximum
Range (Std) Alcance (Std) |
156 NM |
Dimensions / Dimensiones |
|||
Fuselage
Length Fuselaje Largo |
25,59 ft |
Main
Rotor Diameter Diam. Rotor Principal |
32,34 ft |
Length,
Rotors Turning Dist. Rotores Girando |
39,00 ft |
Tail
Rotor Diameter Diam. Rotor de Cola |
6,00 ft |
Total
Height Alto Total |
7,50 ft |
Price Precio |
NA |
